LC Power LC600-12 V2.31 / Power supply (internal) / ATX12V 2.31 / 80 PLUS Bronze / 450 Watt / active PFC | LC600-12 V2.31
Please sign in so that we can notify you about a reply
Special Features
- 450 W max. / peak
- High efficiency
- Low standby consumption
- Large fan
- 1x PCI-Express 6 pin, 1x PCI-Express 6+2 pin
Product Specification
| Device Type | Power supply - active Power Factor Correction (PFC) - internal |
| Specification Compliance | ATX12V 2.31 |
| PSU Form Factor | ATX |
| Power Device | Power Device |
| Power Output Connectors Details | 1 x power 24 pin ATX with detachable 4 pin section ¦ 1 x power 8 pin +12V with detachable 4 pin section ¦ 1 x 6 pin PCI Express power ¦ 1 x 8 pin PCI Express power with detachable 2 pin section ¦ 6 x 15 pin Serial ATA power ¦ 3 x 4 PIN internal power ¦ 2 x 4 PIN mini-power connector |
| Output Voltage | +3.3, +5, +12 V |
| Power Capacity | 450 Watt |
| Output Current | +3.3V - 24 A ¦ +5V - 15 A ¦ +12V1 - 17 A ¦ +12V2 - 14 A |
| Efficiency | 89.14% |
| 80 PLUS Certification | 80 PLUS Bronze |
| Miscellaneous | Miscellaneous |
| Cooling System | 120 mm fan |
| Features | Over voltage protection, overpower protection, undervoltage protection, short-circuit protection, Intel 4th-gen CPU (Haswell) compatible |
| Compliant Standards | TUV |
| Dimensions & Weight | Dimensions & Weight |
| Width | 15 cm |
| Depth | 14 cm |
| Height | 8.5 cm |
| Weight | 1.439 kg |
Features - LC-Power - LC600-12 V2.31
More Details
Product Code
04:146395
EAN Code
4260070124419
Manufacturer
LC-Power
