Lenovo ThinkSystem ST50 V2 7D8J / Server / tower / 5U / 1-way / 1 x Xeon E-2324G / 3.1 GHz / RAM 16 GB / SSD 2 x 960 GB / UHD Graphics P750 / no OS / monitor: none | 7D8JA043EA
Please sign in so that we can notify you about a reply
Special Features
- Improved single-socket processor performance
- Up to four 3200 MHz DDR4 ECC UDIMMs provide speed and capacity of up to 64 GB
- Three PCIe slots for I/O expansion, one of which has a PCIe Gen4 interface to maximize I/O performance
- Support for an NVMe M.2 drive for OS boot operations
- Up to three non-hot-swap (NHS) drive bays, two 3.5-inch and one 2.5-inch, supporting hard disk drives (HDDs) or solid-state drives (SSDs) provide flexible internal storage capacity
Product Specification
| Type | Server |
| Product Form Factor | Tower - 5U |
| Embedded Security | Trusted Platform Module (TPM 2.0) Security Chip |
| Server Scalability | 1-way |
| Internal Bays Qty | 2 |
| Localisation | Region: EMEA |
| Processor / Chipset | Processor / Chipset |
| CPU | Intel Xeon E-2324G |
| Clock Speed | 3.1 GHz |
| Max Turbo Speed | 4.6 GHz |
| Number of Cores | Quad-Core |
| CPU Qty | 1 |
| Max CPU Qty | 1 |
| CPU Socket | LGA1200 Socket |
| Chipset Type | Intel C256 |
| Cache Memory | Cache Memory |
| Installed Size | 8 MB |
| Cache Per Processor | 8 MB |
| RAM | RAM |
| Installed Size | 16 GB / 128 GB (max) |
| Technology | DDR4 SDRAM - ECC |
| Effective Memory Speed | 3200 MHz |
| Rated Memory Speed | 3200 MHz |
| Form Factor | DIMM 288-pin |
| Slots | 4 (Total) / 3 (empty) |
| Features | Unbuffered |
| Configuration Features | 1 x 16 GB |
| Hard Drive | Hard Drive |
| Type | SSD |
| Capacity | 2 x 960 GB |
| Interface Type | SATA 6Gb/s |
| Storage Controller | Storage Controller |
| Type | 1 x SATA |
| Controller Interface Type | SATA 6Gb/s |
| Channel Qty | 3 |
| RAID Level | JBOD |
| Optical Storage | Optical Storage |
| Type | No optical drive |
| Monitor | Monitor |
| Monitor Type | None. |
| Graphics Controller | Graphics Controller |
| Graphics Processor | Intel UHD Graphics P750 Shared Video Memory (UMA) |
| Video Interfaces | DisplayPort |
| Networking | Networking |
| Ethernet Controller | Intel I219-LM |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Features | Wake on LAN (WoL), Teaming support, Intel Active Management Technology (AMT) 15 |
| Compliant Standards | DASH 1.1 |
| Expansion / Connectivity | Expansion / Connectivity |
| Bays | 1 (total) / 1 (free) x external 5.25" ¦ 2 (total) / 0 (free) x internal 3.5" |
| Slots | 1 (total) / 1 (free) x PCIe 4.0 x16 - half-length, full-height ¦ 1 (total) / 1 (free) x PCIe 3.0 x1 - half-length, full-height ¦ 1 (total) / 1 (free) x PCIe 3.0 x16 - half-length, full-height (x4 mode) |
| Interfaces | 1 x USB-C 3.2 Gen 2 (1 in front) ¦ 2 x USB 3.2 Gen 2 (2 in front) ¦ 6 x USB 3.2 Gen 1 (2 front, 4 rear) ¦ 2 x DisplayPort ¦ 1 x LAN (Gigabit Ethernet) ¦ 1 x serial ¦ 1 x audio line-out ¦ 1 x VGA (on supplied cable) |
| Miscellaneous | Miscellaneous |
| Theft/Intrusion Protection | Security lock slot (cable lock sold separately), padlock loop |
| Security Slot Type | Kensington security slot |
| Compliant Standards | TUV GS, BSMI, IEC 60950-1, GB 17625.1, VCCI Class A, GB 4943.1, INMETRO, NOM-019, EK1-ITB2000, UL 2819, AS/NZS CISPR 32 Class A, KN32 Class A, EN 62368-1, IEC 62368-1, EN 55032 Class A, CISPR 32 Class A, TP TC 004/2011, HJ 2507-2011, Energy-Related Products (ErP) Lot 9, TP EAC 037/2016, ANSI/UL 62368-1, ICES-003 issue 7 Class A, GB/T9254, CQC3135, CSA C22.2 No. 62368-1, CMIM |
| Power | Power |
| Device Type | Power supply |
| Voltage Required | AC 100-240 V (50/60 Hz) |
| Power Provided | 500 Watt |
| 80 PLUS Certification | 80 PLUS Platinum |
| Efficiency | 94% |
| Operating System / Software | Operating System / Software |
| OS Provided | No operating system |
| Manufacturer Warranty | Manufacturer Warranty |
| Service & Support | Limited warranty - 3 years - on-site - response time: next business day |
| Dimensions & Weight | Dimensions & Weight |
| Width | 17 cm |
| Depth | 31.6 cm |
| Height | 37.6 cm |
| Weight | 9.4 kg |
| Dimensions & Weight (Shipping) | Dimensions & Weight (Shipping) |
| Shipping Width | 28 cm |
| Shipping Depth | 42 cm |
| Shipping Height | 54 cm |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | 10 °C |
| Max Operating Temperature | 35 °C |
| Humidity Range Operating | 8 - 80% |
