LevelOne FCS-7004 / Video server / 4 channels | FCS-7004
Please sign in so that we can notify you about a reply
Special Features
- Real-time H.264, MJPEG compression
- Dual stream simultaneously
- Powered by 12 V DC/PoE 802.3af
- 2-way audio
- RS-485 and RS-422
- Memory card slot
Product Specification
| Device Type | Video server |
| Video Channels | 4 |
| Audio Channels | 4 |
| TV System | NTSC/PAL |
| Image Resolution | 720x480 (NTSC), 720x576 (PAL), 960x576 (PAL), 960x480 (NTSC) |
| Compression Format | MJPEG, H.264 |
| Package Content | Software, video server |
| Compliant Standards | EN55024, EN55022 Class B, FCC Part 15 B |
| Video Server | Video Server |
| Frame Rate | 30 fps |
| Features | Motion detection, Pan/Tilt/Zoom support, dual stream support, two-way audio support, microSD/SDHC/SDXC memory card slot |
| Networking | Networking |
| Network Interfaces | Ethernet 10Base-T/100Base-TX |
| Features | Power over Ethernet (PoE) |
| Connections | Connections |
| Video Input Ports | BNC x 4 |
| Video Input Signal Level | 1.0Vp-p 75 Ohm |
| Audio Input Ports | Terminal block x 4 |
| Audio Output Ports | Terminal block |
| Camera Control Interface (PTZ) | RS-422/485 |
| Network Port | 10/100Base-T (PoE) |
| Dimensions & Weight | Dimensions & Weight |
| Width | 13.7 cm |
| Depth | 3.55 cm |
| Height | 12.18 cm |
| Weight | 462 g |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | -10 °C |
| Max Operating Temperature | 50 °C |
| Humidity Range Operating | 10 - 85% (non-condensing) |
Features - LevelOne - FCS-7004
More Details
Product Code
04:245393
EAN Code
4015867190319
Manufacturer
LevelOne
