LevelOne USB-0504 / Hub / 3 x SuperSpeed USB 3.0 + 1 x 10/100/1000 / desktop | USB-0504
LevelOne USB-0504 / Hub / 3 x SuperSpeed USB 3.0 + 1 x 10/100/1000 / desktop | USB-0504
Description
The LevelOne USB-C Hub and Gigabit Ethernet Combo Adapter allows you to connect to the internet easily through the built-in USB-C port on your laptop. This is an ideal solution for MacBook or other Windows computers that may have wireless built-in but don't come with an Ethernet port. Sometimes you need to physically connect to a network cable to help transfer files or access secure information. The USB-0504 easily does the job, all through your USB-C port. The USB-0504 also combines a regular USB hub. So you can connect external USB peripherals, such as a MP3 player, digital camera, printer or pen drive. The USB-0504 establishes a direct point-to-point contact between the hub and the adapter that plugged into your PC.The USB-0504 is USB 1.0, 2.0, and 3.0 compliant. It also follows the Ethernet standards set by the IEEE 802.3/3u and 802.3ab, allowing you to take advantage of Gigabit Ethernet speeds of up to 1000Mbps. This provides a strong backbone for any high-speed broadband connection to the internet as well as fast speeds for the Local Area Network file transfers.This makes the USB-0504 the best choice for reliability, efficiency and standard compliance.
LevelOne USB-0504 / Hub | USB-0504
Special Features
- 10/100/1000Mbps wire speed transmission and reception
- Built-in 3-port super speed USB 3.0 hub
- Compatible with USB 3.0 / 2.0 standards
- Built-in Wake-on-LAN feature to startup/shutdown computers remotely
- Multi-platform support: Windows, Mac OS
- Hot-swappable
Product Specification
| Device Type | Hub - 3 ports |
| Enclosure Type | Desktop |
| Subtype | USB |
| Ports | 3 x SuperSpeed USB 3.0 + 1 x 10/100/1000 |
| Features | Flow control, full duplex capability, wake on LAN (WOL), IPv6 support, USB powered, IPv4 support, Energy-Efficient Ethernet (EEE) |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, USB 2.0, USB 3.0, IEEE 802.3az |
| Interfaces | 3 x USB 3.0 Type A ¦ 1 x 1000Base-T RJ-45 |
| Cables Included | 1 x USB-C cable |
| Compliant Standards | RoHS, EMI |
| OS Required | Microsoft Windows XP / Vista / 7 / 8 / 10, Apple MacOS X 10.6 - 10.13 |
| Width | 9.5 cm |
| Depth | 2.7 cm |
| Height | 1.6 cm |
| Weight | 41 g |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 40 °C |
| Min Storage Temperature | -5 °C |
| Max Storage Temperature | 80 °C |
| Humidity Range Storage | 85% (non-condensing) |
