LevelOne WAN-2182 / Antenna / panel / Wi-Fi / 18 dBi / directional / Indoor / Outdoor, pole mount | WAN-2182
Please sign in so that we can notify you about a reply
Special Features
- Provides 18dBi directional operation
- Directional operation provides extended point to point coverage
- For IEEE 802.11b/g/n Wireless applications in 2.4GHz frequency range
- Low wind loading
Product Specification
| Product Type | Antenna |
| Width | 33 cm |
| Depth | 29.5 cm |
| Height | 3.5 cm |
| Weight | 1.044 kg |
| Aerial | Aerial |
| Form Factor | Panel |
| Intended For | Wi-Fi |
| Aerial Placing / Mounting | Indoor / Outdoor, pole mount |
| Compatibility | 802.11 b/g/n |
| Frequency Range | 2.4 GHz |
| Gain | 18 dBi |
| Directivity | Directional |
| Voltage Standing Wave Ratio (VSWR) | 2.0:1 |
| Horizontal Beamwidth | 25.8° |
| Vertical Beamwidth | 20.7° |
| Impedance | 50 Ohm |
| Cabling & Wiring | Cabling & Wiring |
| Connector Provided | 1 x N-Series connector female |
| Miscellaneous | Miscellaneous |
| Mounting Kit | Included |
| Features | Weatherproof, vertical polarisation |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | -30 °C |
| Max Operating Temperature | 60 °C |
| Humidity Range Operating | 95% (non-condensing) |
Features - LevelOne - WAN-2182
More Details
Product Code
04:248503
EAN Code
4015867203545
Manufacturer
LevelOne
