LogiLink / Video/audio splitter / 4 x HDMI / desktop | HD0036
Please sign in so that we can notify you about a reply
Special Features
- Compliant to HDMI 1.4 with a bandwidth of 3.4 Gbit/s at 340 MHz per channel (10.2 Gbit/s total)
- Supports UHD 4K/30 Hz and Full 3D
- Support of 36 bit Deep Color (12 bit per channel)
- Compliant with HDCP 1.4
- Supports DDC and CEC function
- Support uncompressed audio such as LPCM7.1
- Support compressed audio such as DTS, Dolby Digital (including DTS-HD Master Audio and Dolby TrueHD)
- ABS chassis
- Power supply over DC cable
- Plug-and-play - no driver installation needed
Product Specification
| Device Type | Video/audio splitter - 4 ports |
| Enclosure Type | Desktop |
| Subtype | HDMI |
| Ports | 4 x HDMI |
| Max Resolution | 4K @ 30 Hz |
| Max Video Bandwidth | 340 MHz |
| Features | 3D support, 4K resolution support, 720p resolution support, LPCM 7.1 support, Dolby TrueHD support, DTS-HD Master Audio support, 1080p resolution support, 36-bit Deep Color support, DTS support, 1080i resolution support, Dolby Digital support |
| Compliant Standards | HDCP 1.4 |
| Status Indicators | Power, HDMI |
| Expansion / Connectivity | Expansion / Connectivity |
| Interfaces | 1 x HDMI input ¦ 4 x HDMI output |
| Power | Power |
| Power Consumption Operational | 5 Watt |
| Miscellaneous | Miscellaneous |
| Compliant Standards | Plug and Play, RoHS, DDC |
| Dimensions & Weight | Dimensions & Weight |
| Width | 5.8 cm |
| Depth | 8.1 cm |
| Height | 1.8 cm |
| Weight | 56 g |
| Dimensions & Weight (Shipping) | Dimensions & Weight (Shipping) |
| Shipping Width | 16 cm |
| Shipping Depth | 10.7 cm |
| Shipping Height | 5 cm |
| Shipping Weight | 170 g |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 70 °C |
| Humidity Range Operating | 10 - 85% (non-condensing) |
| Min Storage Temperature | -10 °C |
| Max Storage Temperature | 80 °C |
| Humidity Range Storage | 5 - 90% (non-condensing) |
Features - LogiLink - HD0036
More Details
Product Code
04:381279
EAN Code
4052792062342
Manufacturer
LogiLink
