Micron / DDR4 / module / 16 GB / DIMM 288-pin / 3200 MHz / PC4-25600 / CL22 / 1.2 V / registered / ECC | MTA18ASF2G72PDZ-3G2R1
MTA18ASF2G72PDZ-3G2R1
Find similar
Delivery
Payment options
Please sign in so that we can notify you about a reply
Micron / DDR4 / module / 16 GB / DIMM 288-pin / 3200 MHz / PC4-25600 / CL22 / 1.2 V / registered / ECC | MTA18ASF2G72PDZ-3G2R1
Product Specification
| Capacity | 16 GB |
| Upgrade Type | Generic |
| Width | 133 mm |
| Depth | 3.9 mm |
| Height | 31.3 mm |
| Type | DRAM memory module |
| Technology | DDR4 SDRAM |
| Form Factor | DIMM 288-pin |
| Module Height (inch) | 1.23 |
| Speed | 3200 MHz (PC4-25600) |
| Latency Timings | CL22 (22-22-22) |
| Access Time | 0.625 ns |
| Data Integrity Check | ECC |
| Features | Temperature monitoring, dual rank, On-Die Termination (ODT), Serial Presence Detect (SPD), sixteen banks, Low-power auto self refresh (LPASR), DBI mode support, registered |
| Module Configuration | 2048 x 72 |
| Chips Organization | 1024 x 8 |
| Voltage | 1.2 V |
| Lead Plating | Gold |
| Compliant Standards | RoHS, halogen-free |
Features - Micron - MTA18ASF2G72PDZ-3G2R1
More Details
Product Code
03:158989
EAN Code
0649528905482
Manufacturer
Micron
