MSI MPG Z490 GAMING EDGE WIFI / Motherboard / ATX / LGA1200 Socket / Z490 / USB-C Gen1, USB 3.2 Gen 1, USB 3.2 Gen 2, USB-C Gen 2x2 / 2.5 Gigabit LAN, Wi-Fi, Bluetooth / onboard graphics (CPU required) / HD Audio (8-channel) | 7C79-005R
Description
The MPG Z490 GAMING EDGE WIFI features M.2 Shield FROZR and Mystic Light RGB LED that allows you to personalize your PC with 16.8 million colors and 29 effects. Onboard 2.5G LAN with LAN manager delivers better network experience. The incorporated Wi-Fi 6 solution supports MU-MIMO and the BSS color technology, delivering high speeds. Preinstalled I/O shielding ensures better EMI protection and more convenience for installation. Also features MSI Core Boost, DDR4 Boost technologies and one button to control LED on/off easily.
MSI MPG Z490 GAMING EDGE WIFI / Motherboard | 7C79-005R
Special Features
- Lightning USB 20G
- 2.5G LAN with LAN manager
- Aluminum cover
- Wi-Fi 6
- Core Boost
- DDR4 Boost
- M.2 Shield FROZR
- Preinstalled I/O shielding
- EZ LED control
Product features
- Lightning USB 20G
Built-in USB 32 Gen 2x2 port offers the 20Gbps transmission speed, 4X faster than USB 3.2 Gen 1. - 2.5G LAN
Onboard 2.5G LAN with LAN manager, delivering perfect online gaming experience. - Aluminum cover
Fully aluminum IO cover provides the maximum surface of heat dissipation. - Wi-Fi 6
This wireless solution supports MU-MIMO and BSS color technology, delivering high speeds. - Core Boost
With premium layout and fully digital power design to support more cores and provide better performance. - DDR4 Boost
Advanced technology to deliver pure data signals for stunning gaming performance and stability. - M.2 Shield FROZR
Onboard M.2 thermal solution to keep M.2 SSDs safe while preventing throttling, making them run cooler and faster. - Preinstalled I/O shielding
Better EMI protection and more convenience for installation. - EZ LED control
One button to control LED on/off easily.
Product Specification
| Product Type | Motherboard - ATX |
| Chipset Type | Intel Z490 |
| Processor Socket | LGA1200 Socket |
| Max Processors Qty | 1 |
| Compatible Processors | Celeron, Core i5, Core i3, Core i7, Core i9, Pentium Gold (supports 10th Generation Intel Core / Pentium Gold / Celeron) |
| Max Size | 128 GB |
| Technology | DDR4 |
| Bus Clock | 2133 MHz, 2666 MHz, 2933 MHz, 4000 MHz (O.C.), 4400 MHz (O.C.), 4266 MHz (O.C.), 4800 MHz (O.C.) |
| Supported RAM Integrity Check | Non-ECC |
| Registered or Buffered | Unbuffered |
| Features | Dual channel memory architecture, Intel Extreme Memory Profiles (XMP) |
| Type | HD Audio (8-channel) |
| Audio Codec | Realtek ALC1200-VD1 |
| Compliant Standards | High Definition Audio |
| Network Controller | Realtek RTL8125B-CG / Intel AX201 |
| Network Interfaces | 2.5 Gigabit Ethernet, 802.11a/b/g/n/ac/ax, Bluetooth 5.1 |
| Expansion Slots | 1 x CPU ¦ 4 x DIMM 288-pin ¦ 1 x PCIe 3.0 x16 ¦ 2 x PCIe x1 ¦ 1 x PCIe 3.0 x16 (x4 mode) |
| Storage Interfaces | SATA-600 -connectors: 6 x 7pin Serial ATA - RAID 0 / RAID 1 / RAID 10 / RAID 5 ¦ SATA-600 / PCIe 3.0 -connectors: 2 x M.2 - RAID 0 / RAID 1 |
| Interfaces | 1 x LAN (2.5Gigabit Ethernet) ¦ 1 x USB 3.2 Gen 2 ¦ 1 x USB-C Gen2x2 ¦ 1 x audio line-out - mini-jack ¦ 1 x microphone - mini-jack ¦ 1 x audio line-out (center/subwoofer) - mini-jack ¦ 1 x audio line-out (rear) - mini-jack ¦ 1 x audio line-in - mini-jack ¦ 1 x TOSLINK ¦ 2 x USB 2.0 ¦ 1 x PS/2 keyboard / mouse ¦ 1 x DisplayPort ¦ 1 x HDMI ¦ 4 x USB 3.1 Gen 1 |
| Internal Interfaces | 4 x USB 2.0 - header ¦ 2 x USB 3.2 Gen 1 - header ¦ 1 x audio - header ¦ 1 x USB-C Gen 1 - header |
| Power Connectors | 4-pin ATX12V connector, 24-pin main power connector, 8-pin ATX12V connector |
| BIOS Features | MSI ClickBIOS 5 |
| Hardware Features | AMD CrossFireX technology support, MSI Audio Boost, 6 Layer PCB, MSI Mystic Light, MSI Steel Armor, Game Boost, Double ESD Protection, Intel Optane Memory Ready, M.2 Shield FROZR, 12+1+1 Phase Power Design, pre-mounted I/O shield, MSI Core Boost |
| Included Accessories | Case badge |
| Cables Included | 2 x Serial ATA cable |
| Software Included | Drivers & Utilities |
| Width | 30.5 cm |
| Depth | 24.4 cm |
| Service & Support | Limited warranty - 3 years |
