MSI PRO DP10 13M 034DE / SFF / Core i5 1340P / 1.9 GHz / RAM 8 GB / SSD 512 GB / NVMe / Intel Iris Xe Graphics / Win 11 Pro / | 00B0A611-034
Please sign in so that we can notify you about a reply
Product Features
- Empower your business
13th Gen Intel Core i5 delivers computing capability and keeps you in the flow wherever you go. Also, enjoy a more detailed, immersive viewing experience with Intel Iris Xe Graphics. - Bolt to the next power with built-in Thunderbolt 4
Thunderbolt 4 brings speeds up to 40 Gbps, creating one compact port that does it all - delivering the fast and versatile connection to any dock, display, or data device and NAS. - USB 3.2 Gen 2
When backing up your projects at home, you can get all the performance benefits from USB 3.2 Gen 2, combined with the convenience of the reversible USB-C connector port. - Connect all of your devices with Wi-Fi 6E
Wi-Fi 6E puts more emphasis on transmission security and improves the signal. More devices at the same time can also be connected, thereby meeting the trend of higher and higher data transmission bandwidth requirements with speeds up to 2.4 Gbps. - Various I/O ports
With a various array of I/O ports, you can connect all devices you need at the same time so you can multitask and work more efficiently.
Special Features
- Empower your business
- Thunderbolt 4
- USB 3.2 Gen 2
- Wi-Fi 6E
- Various I/O ports
Product Specification
| Type | Personal computer |
| Product Form Factor | Small form factor |
| Built-in Devices | Air cooling solution |
| Embedded Security | Trusted Platform Module (TPM) Security Chip |
| Colour | Black |
| Processor / Chipset | Processor / Chipset |
| CPU | Intel Core i5 (13th Gen) 1340P |
| Clock Speed | 1.9 GHz |
| Max Turbo Speed | 4.6 GHz |
| Number of Cores | 12-core |
| CPU Qty | 1 |
| Max CPU Qty | 1 |
| Cache Memory | Cache Memory |
| Installed Size | 12 MB |
| Cache Per Processor | 12 MB |
| RAM | RAM |
| Installed Size | 8 GB / 64 GB (max) |
| Technology | DDR4 SDRAM |
| Effective Memory Speed | 3200 MHz |
| Rated Memory Speed | 3200 MHz |
| Form Factor | SO-DIMM 260-pin |
| Slots | 2 (Total) / 1 (empty) |
| Configuration Features | 1 x 8 GB |
| Hard Drive | Hard Drive |
| Type | SSD - M.2 2280 |
| Capacity | 1 x 512 GB |
| Interface Type | PCI Express 3.0 x4 |
| Features | NVM Express (NVMe) |
| Storage Controller | Storage Controller |
| Type | 1 x SATA |
| Optical Storage | Optical Storage |
| Type | No optical drive |
| Monitor | Monitor |
| Monitor Type | None. |
| Graphics Controller | Graphics Controller |
| Graphics Processor | Intel Iris Xe Graphics |
| Video Interfaces | HDMI, DisplayPort |
| Audio Output | Audio Output |
| Sound Output Mode | 2.1 channel surround |
| Compliant Standards | High Definition Audio |
| Networking | Networking |
| Wireless LAN Supported | Yes |
| Wireless NIC | Intel Wi-Fi 6E AX 211 |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6E), Bluetooth 5.3 |
| Expansion / Connectivity | Expansion / Connectivity |
| Bays | 1 (total) / 1 (free) x internal 2.5" |
| Slots | 2 (total) / 1 (free) x M.2 Card |
| Interfaces | 1 x audio line-in/headphones (1 in front) ¦ 5 x USB 3.2 Gen 1 (3 front, 2 rear) ¦ 1 x USB-C 3.2 Gen 2 (1 front) ¦ 1 x HDMI ¦ 1 x Thunderbolt 4 ¦ 1 x LAN (Gigabit Ethernet) ¦ 1 x DisplayPort 1.4 ¦ 1 x VGA ¦ 1 x Wi-Fi aerial |
| Miscellaneous | Miscellaneous |
| Theft/Intrusion Protection | Security lock slot (cable lock sold separately) |
| Security Slot Type | Kensington security slot |
| VESA Mounting Interface | 75 x 75 mm |
| Compliant Standards | FCC Class B certified, VCCI, C-Tick, BSMI, CB, RCM, UL/cUL |
| Power | Power |
| Device Type | Power supply |
| Power Provided | 120 Watt |
| Operating System / Software | Operating System / Software |
| OS Provided | Windows 11 Pro |
| Manufacturer Warranty | Manufacturer Warranty |
| Service & Support | Limited warranty - 3 years |
| Dimensions & Weight | Dimensions & Weight |
| Width | 3.448 cm |
| Depth | 17.882 cm |
| Height | 1.79 cm |
| Weight | 1.1 kg |
| Dimensions & Weight (Shipping) | Dimensions & Weight (Shipping) |
| Shipping Width | 53 cm |
| Shipping Depth | 32 cm |
| Shipping Height | 53 cm |
| Shipping Weight | 2.1 kg |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 35 °C |
| Humidity Range Operating | 0 - 90% |
Features - MSI - 00B0A611-034
CPU Type
- Intel Core i5
Capacity
512GB
More Details
Product Code
04:423965
EAN Code
4711377071123
Manufacturer
MSI
