Description Each port automatically detects which speed is needed by the connected device and provides the adequate speed. As opposed to regular 10-Gigabit switches that will only provide 1-Gigabit connectivity to any device that require less than 10-Gigabit, the switch gives the exact speed required, with no downgrade. Also, the NETGEAR Multi-Gigabit switch ports can connect regular CAT5e Ethernet cables, without the need to upgrade to CAT6 wiring, therefore reducing wiring costs and hassle. Access, aggregation or collapsed core: you can now have your PCs, printers and routers/firewalls connected at 1G and aggregate Multi-Gigabit Ethernet devices on the same switch, all line-rate. 10G copper and fiber ports are ready for local servers and storage, or high-speed aggregation to your network core. Special Features
|
Product Specification
Device Type | Switch - 8 ports - L3 Lite - smart |
Enclosure Type | Desktop, rack-mountable |
Subtype | 10 Gigabit Ethernet |
Ports | 4 x 10/100/1000 (PoE+) + 2 x 100/1000/2.5G/5G (PoE+) + 2 x 100/1000/2.5G (PoE+) |
Power Over Ethernet (PoE) | PoE+ |
PoE Budget | 180 W |
Performance | Bandwidth: 78 Gbps ¦ Latency (10 Gbps): |
Capacity | LAG groups: 8 ¦ MAC addresses: 16000 ¦ ACL entries (ingress): 164 ¦ Virtual interfaces (VLANs): 256 ¦ RP/NDP table: 512 ¦ IPv4 routes (static): 32 ¦ IPv6 routes (static): 32 ¦ IGMP multicast groups: 512 ¦ ARP entries: 512 ¦ VLAN routing interfaces: 32 ¦ Jumbo frame size: 10000 ¦ DHCP snooping entries: 1000 ¦ Multicast groups: 512 ¦ Priority queues: 8 |
MAC Address Table Size | 16K entries |
Routing Protocol | Static IP routing |
Remote Management Protocol | SNMP 1, SNMP 2, RMON 1, RMON 2, RMON 3, RMON 9, SNMP 3, SNMP 2c |
Encryption Algorithm | SSL |
Authentication Method | RADIUS |
Features | IGMP snooping, Syslog support, DoS attack prevention, port mirroring, DiffServ support, Broadcast Storm Control, Multicast Storm Control, Unicast Storm Control, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, Access Control List (ACL) support, Quality of Service (QoS), Jumbo Frames support, Dynamic ARP Inspection (DAI), LACP support, LLDP support, Energy Efficient Ethernet, Class of Service (CoS), 802.1x authentication, Type of Service (ToS), DiffServ Code Point (DSCP) support, 1.5MB packet buffer, MAC and IP-based ACLs support, 1 fan, Voice VLAN, VLAN management, Guest VLAN, Weighted Round Robin (WRR), Auto VoIP, MAC lockdown, IPv6 management |
Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3an, IEEE 802.3az, ITU-T H.323, IEEE 802.3bz |
Processor | : 800 MHz |
RAM | 512 MB |
Flash Memory | 256 MB |
Status Indicators | Power, PoE, fan, link/activity/speed |
Interfaces | 4 x 1000Base-T - RJ-45 - PoE+ ¦ 2 x 100/1000/2.5G/5G - RJ-45 - PoE+ ¦ 2 x 100/1000/2.5G - RJ-45 - PoE+ ¦ 1 x 100/1000/2.5G/5G/10GBase-T - SFP+ - dedicated ¦ 1 x 10GBase-X - SFP+ - dedicated ¦ USB |
Power Device | Internal power supply |
Rack Mounting Kit | Included |
MTBF | 376,434 hours |
Compliant Standards | EN 60950, UL 1950, ANSI C63.4, EN 60950-1:2006, GB4943.1-2011, IEC 60950-1:2005, EN 61000-3-3:2013, EN 55024:2010, YD/T993-1998, EN 61000-3-2:2014, FCC CFR47 Part 15 A, CNS 13438 Class A, EN 55032:2012, CNS 14336-1, IEC 950, ICES-003:2016 issue 6 Class A, CISPR 32:2012, VCCI-CISPR 32:2016 Class A, AN/NZS 60950.1:2015, AS/NZS CISPR32:2013 Class A |
Localisation | Europe |
Width | 32.8 cm |
Depth | 16.9 cm |
Height | 4.3 cm |
Weight | 1.9 kg |
Service & Support | Limited warranty - replacement - lifetime - response time: next business day ¦ Limited warranty - phone consulting - 90 days |
Min Operating Temperature | 0 °C |
Max Operating Temperature | 50 °C |
Humidity Range Operating | 90% (non-condensing) |
Min Storage Temperature | -20 °C |
Max Storage Temperature | 70 °C |
