NETGEAR S3600 Series XS516TM / Switch / 2+/L3 Lite / smart / 16 x 10/25 Gigabit Ethernet + 2 x 10Gb Ethernet SFP+ (uplink) / desktop, rack-mountable | XS516TM-100EUS
Please sign in so that we can notify you about a reply
Product Features
- 10G Base-T copper Ethernet
Supports high-density VoIP, surveillance and Wi-Fi AP deployments, scalable for future growth. - 10G 1000Base-X SFP ports
10G SFP+ ports for aggregation to the network core. Support for fiber and copper modules. - Low acoustics
Temperature- and load-based fan-speed control allows for quiet operation in both desktop, wall mount or rack mount configuration. - Energy-efficient Ethernet (IEEE 802.3az)
Maximum power reduction for ongoing operation cost savings. Flexible deployment on desktop and also supports wall mounting and rack mounting. - Ideal companion to your Pro Wi-Fi access points
Connect and manage all Pro Wi-Fi access points from a single dashboard with NETGEAR Insight Remote Cloud Management.
Special Features
- 10G Base-T copper Ethernet
- 10G 1000Base-X SFP ports
- Low acoustics
- Energy-efficient Ethernet (IEEE 802.3az)
- Ideal companion to your Pro Wi-Fi access points
Product Specification
| Device Type | Switch - 16 ports - 2+/L3 Lite - smart |
| Enclosure Type | Desktop, rack-mountable |
| Subtype | 10 Gigabit Ethernet |
| Ports | 16 x 10/25 Gigabit Ethernet + 2 x 10Gb Ethernet SFP+ (uplink) |
| Performance | Non-blocking bandwidth: 360 Gbps |
| Capacity | Multicast groups: 512 ¦ IPv4 routes (static): 64 ¦ IPv6 routes (static): 32 ¦ DHCP snooping entries: 256 ¦ ARP table: 1024 ¦ VLAN routing interfaces: 15 ¦ ACL entries (ingress): 100 ¦ Packet buffer size: 4 MB |
| MAC Address Table Size | 16000 entries |
| Jumbo Frame Support | 9KB |
| Routing Protocol | IGMP, IGMPv3, MLD, IPv4-to-IPv6 Multicast |
| Remote Management Protocol | SNMP 1, RMON, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, CLI, DHCP, IPv4, IPv6, Web GUI |
| Authentication Method | RADIUS, TACACS+ |
| Features | IGMP snooping, DoS attack prevention, port mirroring, DHCP snooping, RADIUS support, Dynamic VLAN Support (GVRP), dual firmware images, loop prevention, Strict Priority (SP), VoIP support, 3 fans, cable test, IGMP querier, DNS client, LLDP-MED, Weighted Round Robin (WRR), egress rate limiting, Advanced QoS, MLD querier, loop detection, syslog server, static IP address support, LACP, MVR, Auto Power Down |
| Compliant Standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3az |
| Processor | : 600 MHz |
| RAM | 1 GB |
| Flash Memory | 256 MB |
| Status Indicators | Power, fan, link/activity/speed |
| Expansion / Connectivity | Expansion / Connectivity |
| Interfaces | 8 x 1000Base-T RJ-45 ¦ 2 x 1000Base-X SFP+ dedicated |
| Power | Power |
| Power Device | Internal power supply |
| Voltage Required | (50 - 60 Hz) |
| Power Consumption Operational | 32.7 Watt |
| Miscellaneous | Miscellaneous |
| Included Accessories | Wall mounting kit, power cord |
| Rack Mounting Kit | Included |
| MTBF | 815,463.9 hours |
| Localisation | United Kingdom, Europe |
| Software / System Requirements | Software / System Requirements |
| Software Included | NETGEAR Insight (1 year subscription) |
| Dimensions & Weight | Dimensions & Weight |
| Width | 33 cm |
| Depth | 20.6 cm |
| Height | 4.32 cm |
| Weight | 2.2 kg |
| Manufacturer Warranty | Manufacturer Warranty |
| Service & Support | Limited warranty - replacement - lifetime - response time: next business day ¦ Technical support - 90 days |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 50 °C |
| Humidity Range Operating | 95% RH (non-condensing) |
| Min Storage Temperature | -20 °C |
| Max Storage Temperature | 70 °C |
| Humidity Range Storage | 95% RH (non-condensing) |
Features - NetGear - XS516TM-100EUS
General
16-Port
More Details
Product Code
CJ51893
EAN Code
0606449165463
Manufacturer
NetGear
