NETGEAR ProSAFE XS748T / Switch / L3 Lite / smart / 44 x 10GBase-T + 4 x 10 Gigabit SFP+ / desktop, rack-mountable | XS748T-100NES

Description
Features

NETGEAR ProSAFE XS748T / Switch / L3 Lite / smart / 44 x 10GBase-T + 4 x 10 Gigabit SFP+ / desktop, rack-mountable | XS748T-100NES

Description

The XS748T 10-Gigabit Ethernet Smart Managed Switch brings the second generation of 10-Gigabit Copper switching to SMBs. The XS748T is a powerful Smart Managed Switch that includes 44 ports of 10-Gigabit connectivity (44 copper with 4 dedicated 10-Gigabit SFP+ Fiber ports). NETGEAR's 10-Gigabit Smart Managed Switches are purposely designed as a cost-effective way to provide 10G connections to 10G-capable servers and NAS (Network Attached Storage) systems. The XS748T provides comprehensive L2+/Layer 3 Lite features (including IPV6 management) allowing SMB customers to deploy virtualization, cloud-based services and applications like VoIP, video streaming and IP surveillance, which require higher reliability, speed, and performance. It can be used at the "center of a small business network" or as an aggregation/access switch in a larger organization. The XS748T is ideal for is ideal for expanding network capacity, removing performance bottlenecks and/or support of premise expansion needs.

Special Features

Advanced VLAN features such as Protocol-based VLAN, MAC-based VLAN and 802.1x Guest VLAN
Advanced QoS with L2 / L3 / L4 awareness and 8 priority queues
IPv4 and IPv6 static routing
Private VLAN
Dynamic VLAN assignment
IGMP and MLD snooping
Advanced security
IPv6 for management, QoS and ACL

Product features

Comprehensive L2+ / Layer 3 Lite features
The ProSAFE 10G Smart Managed Switch provides comprehensive L2+ / Layer 3 Lite features in order to meet current and future needs on virtualization, converged networking and mobility.
Smart IT, not big IT
Easy-to-use web browser-based management GUI makes setup and management simple. It features a standards-based technology, ensuring interoperability with any standards-based devices in the existing network, as well as dual firmware images, improving reliability and uptime to your network.
10-Gigabit transition with BASE-T
10GBASE-T, like other BASE-T technologies, uses the standard RJ-45 Ethernet jack. It is backward compatible, auto-negotiating between higher and lower speeds - thereby not forcing an all-at-once network equipment upgrade.

Product Specification

Device Type	Switch - 48 ports - L3 Lite - smart
Enclosure Type	Desktop, rack-mountable 1U
Subtype	10 Gigabit Ethernet
Ports	44 x 10GBase-T + 4 x 10 Gigabit SFP+
Performance	Switching fabric bandwidth: 960 Gbps ¦ Forwarding performance (64-byte packet size): 238 Mpps
Capacity	ACL: 164 ¦ Virtual interfaces (VLANs): 512 ¦ IGMP groups: 512 ¦ IPv4 routes: 64 ¦ IPv6 routes: 64 ¦ Priority queues per port: 8 ¦ ARP entries: 1024 ¦ DHCP snooping entries: 1000
MAC Address Table Size	16K entries
Jumbo Frame Support	10KB
Routing Protocol	Static IPv4 routing, static IPv6 routing
Remote Management Protocol	SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, SNMP 3, SNMP 2c, HTTP, HTTPS
Encryption Algorithm	TLS 1.0, SSL 2.0, TLS 1.2
Authentication Method	RADIUS, TACACS+
Features	Flow control, ARP support, VLAN support, IGMP snooping, Syslog support, DoS attack prevention, port mirroring, DiffServ support, Weighted Round Robin (WRR) queuing, store and forward, MAC address filtering, Broadcast Storm Control, IP address filtering, Unicast Storm Control, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, DHCP snooping, Access Control List (ACL) support, Quality of Service (QoS), RADIUS support, MLD snooping, reset button, LACP support, LLDP support, Port Security, DHCP client, Energy Efficient Ethernet, Strict Priority Queuing (SPQ), Class of Service (CoS), 802.1x authentication, Type of Service (ToS), DiffServ Code Point (DSCP) support, 4 fans, 3MB packet buffer, cable test, layer 2+ switching
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3an, IEEE 802.3az
Processor	: 800 MHz
RAM	512 MB
Flash Memory	256 MB
Status Indicators	Port transmission speed, power, link/activity, fan
Interfaces	44 x 10GBase-T - RJ-45 ¦ 4 x 10GBase-X - SFP+ ¦ 1 x USB 2.0 - management
Power Device	Internal power supply
Power Consumption Operational	262.8 Watt
Included Accessories	Rubber feet
Rack Mounting Kit	Included
MTBF	483,808 hours
Compliant Standards	cUL, EN 60950, IEC950, UL 1950, EN55024, CSA 22.2 No. 950, EN55022 Class A, CISPR 22, CCC, FCC Part 15 A, C-Tick Class A, SCC, VCCI Class A, TLS v1.2, TLS v1.0, EN 55024
Localisation	Latin America, North America, Europe
Software Included	Drivers & Utilities
Width	44 cm
Depth	31 cm
Height	4.3 cm
Weight	6.25 kg
Service & Support	NETGEAR lifetime warranty
Min Operating Temperature	0 °C
Max Operating Temperature	50 °C
Humidity Range Operating	90% (non-condensing)
Min Storage Temperature	-20 °C
Max Storage Temperature	70 °C
