PowerWalker VFD 600 APFC FR - UPS - AC 220/230/240 V - 300 Watt - 600 VA - 5 Ah - output connectors: 6 - black | 10120412
10120412
Find similar
Delivery
Payment options
Please sign in so that we can notify you about a reply
Special Fetures
- Supports full rating APFC power supplies
- Most economic back up solution
- Easy user-replaceable battery design
Product Specification
| Device Type | UPS - external |
| Colour | Black |
| Power Device | |
| UPS Technology | Off-line |
| Input Voltage | AC 220/230/240 V |
| Input Voltage Range | AC 170 - 280 V |
| Frequency Provided | 50/60 Hz ± 1Hz |
| Frequency Required | 50/60 Hz |
| Input Connectors | 1 x power CEE 7/7 |
| Power Output Connectors Details | 4 x power CEE 7/5 (UPS and surge) ¦ 2 x power CEE 7/5 (surge) |
| Output Voltage | AC 220/230/240 V ± 10% - 50/60 Hz |
| Power Capacity | 300 Watt / 600 VA |
| Dataline Surge Protection | Network/phone line - RJ-45/RJ-11 - 1 input line / 1 output line |
| Output Waveform | Sinewave |
| Surge Suppression | Yes |
| Efficiency | 95% |
| Battery | |
| Quantity | 1 |
| Voltage Provided | 12 V |
| Capacity | 5 Ah |
| Run Time (Up To) | 2 min at full load ¦ 8 min at half load |
| Recharge Time | 10 hours |
| Transfer Time | 8 ms |
| Miscellaneous | |
| Cables Included | Power cable - integrated |
| Features | Audible alarm, LED indicators, cold-start function |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 2 years |
| Environmental Parameters | |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 40 °C |
| Humidity Range Operating | 0 - 85% (non-condensing) |
| Dimensions & Weight | |
| Width | 12.5 cm |
| Depth | 32 cm |
| Height | 8.6 cm |
| Weight | 2.8 kg |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 15.2 cm |
| Shipping Depth | 37.8 cm |
| Shipping Height | 19 cm |
| Shipping Weight | 3.4 kg |
