PowerWalker VFI 1000 AT FR - UPS - AC 80-300 V - 900 Watt - 1000 VA - 9 Ah - RS-232, USB - output connectors: 3 | 10122183
Please sign in so that we can notify you about a reply
Special Fetures
- USB with Human Interface Device (HID) support and Intelligent Slot for communication cards
- Wide input voltage range for all environments and support for AC generator
- Auto dimming screen (UPS is woken up with a single button click)
Product Specification
| Device Type | UPS - external |
| Power Device | |
| UPS Technology | On-line |
| Input Voltage | AC 80-300 V |
| Frequency Provided | ± 0.5% |
| Input Voltage Margin | + 1% / - 1% |
| Frequency Required | 40 - 70 Hz |
| Input Connectors | 1 x power IEC 60320 C14 |
| Power Output Connectors Details | 3 x power Type E |
| Output Voltage | AC 208/220/230/240 V + 1% / - 1% |
| Power Capacity | 900 Watt / 1000 VA |
| Dataline Surge Protection | Network/phone line - RJ-45/RJ-11 - 1 input line / 1 output line |
| Output Waveform | Sinewave |
| Surge Suppression | Yes |
| Power Factor (PF) | 0.9 |
| Battery | |
| Quantity | 2 |
| Voltage Provided | 12 V |
| Capacity | 9 Ah |
| Run Time (Up To) | 3.5 min at full load ¦ 11 min at half load |
| Recharge Time | 4 hours |
| Networking | |
| Remote Management Interface | RS-232, USB |
| Expansion / Connectivity | |
| Interfaces | 1 x management (USB) ¦ 1 x management (RS-232) ¦ 1 x EPO (emergency power off) |
| Expansion Slots | 1 (total) / 1 (free) x Expansion Slot |
| Miscellaneous | |
| Features | LCD display, generator compatible, Human Interface Device (HID) support |
| Software / System Requirements | |
| Software Included | PowerMaster |
| Dimensions & Weight | |
| Width | 14 cm |
| Depth | 32.7 cm |
| Height | 19.1 cm |
| Weight | 9.11 kg |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 21.8 cm |
| Shipping Depth | 43.2 cm |
| Shipping Height | 27.4 cm |
| Shipping Weight | 9.95 kg |
Features - Bluewalker - 10122183
More Details
Product Code
04:379215
EAN Code
4260074982480
Manufacturer
Bluewalker
