Product Specification
| Device Type | Hard drive array |
| Enclosure Type | Rack-mountable - 2U |
| Installed Devices / Modules Qty | 0 |
| Supported Devices / Modules Qty | 12 |
| Supported Drives | SATA-600 |
| HDD Array External Interface | SATA 6Gb/s |
| Type | SATA |
| Interface Type | SATA 6Gb/s |
| RAID Level | JBOD |
| Type | No HDD |
| Expansion Bays | 12 (total) / 12 (free) x hot-swap - 2.5" / 3.5" shared |
| Interfaces | 3 x SAS 6Gb/s - 26 pin 4x Mini MultiLane SAS (SFF-8088) |
| OS Required | Linux, Microsoft Windows, QNAP QTS, QNAP QTS hero |
| Features | Built-in 2 cooling fans |
| Cables Included | 3 x SFF-8644 to SFF-8088 SAS cable |
| Included Accessories | 2 power cords, 36 flat head screws (for 2.5" HDD), 48 x flat head screws (for 3.5" HDD), QNAP QXP SATA Expansion Card |
| Power Device | Internal power supply |
| Power Redundancy | Yes |
| Voltage Required | AC 120/230 V |
| Power Provided | 250 Watt |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 40 °C |
| Humidity Range Operating | 5 - 95% (non-condensing) |
| Sound Emission | 33.7 dBA |
