Samsung PM55F / 55" Class / PMF Series LED display / digital signage / 1080p (Full HD) / edge-lit | LH55PMFPBGC/EN
Samsung PM55F / 55" Class / PMF Series LED display / digital signage / 1080p (Full HD) / edge-lit | LH55PMFPBGC/EN
Description Boasting of slim depth design, Samsung's PMF series standalone displays provide a compact, but strong signage solution for environments limited by space or configuration. These standalone displays feature a narrow-bezel configuration to further maintain viewers' focus aimed at on-screen content. The standalone displays' integrated centralized infrared receiver (IR) ensures easier and more flexible user control. All models can receive the IR signal on individual panels via Central IR. Through tailored installation or mounting, users can navigate the IR functionality from various locations, further augmenting uninterrupted performance. Equipped with a non-glare frontal panel, the PMF series displays reduce natural and ambient light interference to ensure continuous readability in any location. Image visibility and information readability are deemed to be very high, because it is less reflective under light or sunlight, which poses no issues when used with QSR menu boards, or airport flight schedule boards with ample natural light. Special Features
Product features
|
Product Specification
Product Type | LED-backlit LCD flat panel display |
Energy Class | Class A |
Power Consumption Operational | 187 Watt |
Power Consumption (On mode) | 115 W |
Energy Consumption per Year | 160 kWh |
Diagonal Class | 55" |
Commercial Use | Yes - digital signage |
Series | PMF Series |
TV Tuner | No tuner |
Sensors | Temperature sensor |
Video Interface | HDMI |
HDMI Ports Qty | 2 ports |
PC Interface | DVI, VGA (HD-15), DisplayPort |
Modes | Portrait mode, landscape mode |
Design | Narrow Bezel Design, swivel screen |
Protection | Dustproof |
Video Wall Components Qty | 225 |
Dimensions | Without stand |
Width | 122.84 cm |
Depth | 2.99 cm |
Height | 70.12 cm |
Weight | 16.3 kg |
Resolution | 1920 x 1080 |
Display Format | 1080p (Full HD) |
Image Aspect Ratio | 16:9 |
Motion Enhancement Technology | 60 Hz Refresh Rate |
LCD Backlight Technology | LED backlight - edge-lit |
Image Contrast Ratio | 5000:1 |
Brightness | 500 cd/m² |
Viewing Angle | 178° |
Viewing Angle (Vertical) | 178° |
Response Time | 8 ms |
Commercial Features | Button lock, HTML5 support, Auto Source Switching & Recovery |
Features | Multiple Display Control (MDC), Certified for 24/7 Continuous Operation, MagicInfo, USB Cloning, Mega Dynamic Contrast Ratio, SSSP 4.0, Center IR |
Stand | Optional |
Flat Panel Mount Interface | 400 x 400 mm |
USB Port | Yes |
USB Ports Qty | 2 |
Operating System | Tizen OS |
Type | Standard remote |
Speaker System | 2 speakers |
Output Power / Total | 20 Watt |
Speakers | 2 x main channel speaker - built-in - 10 Watt |
Connectivity | Wi-Fi |
Connector Type | 2 x HDMI ¦ 2 x USB 2.0 ¦ DVI-I ¦ Audio line-in ¦ Audio line-out ¦ DisplayPort input ¦ DisplayPort output ¦ Multiple Display Control ¦ Serial input ¦ Serial output |
Included Accessories | Batteries |
Cables Included | Serial adapter |
Compliant Standards | Plug and Play, CSA, UL, TUV, VCCI, C-Tick, BSMI, GOST, cUL, NEMKO, NOM, SASO, CB, AS/NZS 60950-1, CCC, PSB, IRAM, EN 60950-1, FCC Part 15 B Class A, KC, GB 9254-2008, NOM-019-SCFI-1998, KN22, KN24, K60950-1, cUL No.60950-1, EAC, GB4943.1-2011, RCM, IP5X, EN55024:1998 + A1:2001 + A2:2003, IS13252, VCCI V-3/2010.04 Class A, CNS 14972, AS/NZS CISPR22:2009, GOST-R 51317 series, GOST 22505-97, EN55022:2006 + A1:2007, CNS 13438 Class A ITE EMI, CNS 13439 AV EMI, CNS 14409 AV EMS, GB 17625.1-2012, NOM-001-SCFI-1993, BIS, INMETRO, IEC60950-1, CE/EMC, KCC/EK |
Power Device | Power supply |
Power Consumption Stand by | 0.5 Watt |
Power Consumption Sleep | 0.5 Watt |
Power Consumption (Off Mode) | 0 Watt |
Width (Shipping) | 133.5 cm |
Depth (Shipping) | 18.2 cm |
Height (Shipping) | 81.2 cm |
Weight (Shipping) | 21.8 kg |
Min Operating Temperature | 0 °C |
Max Operating Temperature | 40 °C |
Humidity Range Operating | 10 - 80% (non-condensing) |
