Sapphire Pulse RX 560 / Graphics card / Radeon RX 560 / 2 GB GDDR5 / PCIe 3.0 x16 / DVI, HDMI, DisplayPort / lite retail | 11267-22-20G
Sapphire Pulse RX 560 / Graphics card / Radeon RX 560 / 2 GB GDDR5 / PCIe 3.0 x16 / DVI, HDMI, DisplayPort / lite retail | 11267-22-20G
Description Built on the future-ready Polaris architecture, the Radeon RX 560 series graphics plays your favorites at a smooth 1080P, from the latest eSports games and MOBAs to the most popular, graphically-intensive AAA titles. With leading DirectX 12 performance, Asynchronous Shaders, game-ready drivers, and frequent software improvements, you'll feel confident that your investment will last for years to come.The Radeon RX 560 series graphics are ready for the display technologies like DisplayPort 1.4 HBR3/HDR, and HDMI 4K60, delivering a high level of graphical fidelity in your favorite games and multimedia experiences. Radeon FreeSync 2 technology means kissing input lag and screen-tearing goodbye, and bathing in super-bright HDR visuals delivering on- screen explosions so vivid you can (almost) feel the heat.Radeon Chill is an intelligent power-saving feature for Radeon graphics that dynamically regulates framerate based on your movements' in-game. During peak gameplay, Radeon Chill works to deliver the full framerate potential of Radeon graphics. As movement decreases, Radeon Chill reduces your gameplay framerate. Designed to save power, lower temperature, and increase battery life, Radeon Chill enables high performance graphics when you battle and saves power when you explore. Sapphire Pulse RX 560 / Graphics card / Radeon RX 560 / 2 GB GDDR5 | 11267-22-20GSpecial Features
Product features
|
Product Specification
Device Type | Graphics card |
Bus Type | PCI Express 3.0 x16 |
Graphics Engine | AMD Radeon RX 560 |
Core Clock | 1216 MHz |
Stream Processors | 896 |
Process Technology | 14 nm |
Max Resolution | 5120 x 2880 at 60 Hz |
Max Resolution Details | DisplayPort: 5120 x 2880 / HDMI: 4096 x 2160 / DVI: 2560 x 1600 |
Max Monitors Supported | 3 |
Interfaces | HDMI ¦ DisplayPort ¦ DVI-D |
API Supported | DirectX 12, OpenGL 4.5, OpenCL 2.0 |
Features | ATI CrossFire Technology, High dynamic-range (HDR) rendering, AMD Eyefinity Technology, Shader Model 5.0, Graphics Core Next (GCN), UEFI BIOS, FreeSync Technology, Frame Rate Target Control(FRTC), AMD XConnect Technology, Radeon ReLive, FreeSync 2 Technology |
Size | 2 GB |
Technology | GDDR5 SDRAM |
Effective Clock Speed | 6 GHz |
Bus Width | 128-bit |
OS Required | Microsoft Windows 7 / 10 |
Required Power Supply | 400 W |
Power Consumption Operational | 45 Watt |
Compliant Standards | DisplayPort 1.4 |
Width | 3.6 cm |
Depth | 21 cm |
Height | 11.2 cm |
Package Type | Lite retail |
