Seasonic CORE GM 500 / Power supply (internal) / ATX12V / EPS12V / 80 PLUS Gold / AC 100-240 V / 500 Watt | CORE-GM-500
CORE-GM-500
Find similar
Delivery
Payment options
Please sign in so that we can notify you about a reply
Product Features
- Semi-modular cables
Some cables are permanently attached to the power supply and the rest of the cables can be used to connect the rest of the available components. - Smart and silent fan control
The intelligent thermal circuit feature is designed to find the optimal balance between the necessity to cool the components and the need to run the power supply in a silent manner.
Special Features
- Semi-modular cables
- Smart and silent fan control
Product Specification
| Device Type | Power supply - internal |
| Specification Compliance | ATX12V / EPS12V |
| PSU Form Factor | ATX |
| Power Device | Power Device |
| Input Voltage | AC 100-240 V |
| Frequency Required | 50 - 60 Hz |
| Power Output Connectors Details | 1 x power 24 pin ATX with detachable 4 pin section ¦ 1 x power 8 pin +12V with detachable 4 pin section ¦ 2 x 8 pin PCI Express power with detachable 2 pin section ¦ 4 x 15 pin Serial ATA power ¦ 3 x 4 PIN internal power |
| Output Voltage | +3.3, +5, ±12 V |
| Power Capacity | 500 Watt |
| Output Current | +5V - 20 A ¦ +3.3V - 20 A ¦ +12V - 41 A ¦ -12V - 0.3 A ¦ +5VSB - 3 A |
| Efficiency | 90% |
| Modular Cable Management | Yes |
| 80 PLUS Certification | 80 PLUS Gold |
| Miscellaneous | Miscellaneous |
| MTBF | 100,000 hours |
| Cooling System | 120 mm fan |
| Features | Overheat protection, over current protection, over voltage protection, overpower protection, undervoltage protection, short-circuit protection, DC-DC technology, fan speed control, sleeve bearing cooling fan, semi-modular, Seasonic S2FC fan Control |
| Compliant Standards | TUV, BSMI, CB, CCC, FCC, RoHS, WEEE, cTUVus, REACH, Energy-Related Products (ErP) Lot 7 |
| Environmental Standards | Environmental Standards |
| ENERGY STAR | Yes |
| Manufacturer Warranty | Manufacturer Warranty |
| Service & Support | Limited warranty - 7 years |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 50 °C |
| Dimensions & Weight | Dimensions & Weight |
| Width | 15 cm |
| Depth | 14 cm |
| Height | 8.6 cm |
Features - Sea Sonic - CORE-GM-500
More Details
Product Code
07:122135
EAN Code
4711173875727
Manufacturer
Sea Sonic
