Seasonic Prime TX 1600 / Power supply (internal) / ATX12V 3.0/ EPS12V / 80 PLUS Titanium / AC 100-240 V / 1600 Watt | PRIME-TX-1600-ATX30
Please sign in so that we can notify you about a reply
Product Specification
| Device Type | Power supply - internal |
| Specification Compliance | ATX12V 3.0/ EPS12V |
| PSU Form Factor | ATX |
| Power Device | Power Device |
| Input Voltage | AC 100-240 V |
| Frequency Required | 50 - 60 Hz |
| Power Output Connectors Details | 1 x power 24 pin ATX with detachable 4 pin section ¦ 3 x power 8 pin EPS12V with detachable 4 pin ATX12V section ¦ 6 x 8 pin PCI Express power with detachable 2 pin section ¦ 3 x 4 PIN internal power ¦ 2 x 12+4 pin PCI Express 5.0 power |
| Output Voltage | +3.3, +5, ±12 V |
| Power Capacity | 1600 Watt |
| Output Current | +3.3V - 25 A ¦ +5V - 25 A ¦ +12V - 133.3 A ¦ -12V - 0.5 A ¦ +5VSB - 3 A |
| Modular Cable Management | Yes |
| 80 PLUS Certification | 80 PLUS Titanium |
| Miscellaneous | Miscellaneous |
| Included Accessories | Screws, case badge, cable ties, cable bag, cable combs, PSU bag, PSU tester |
| MTBF | 100,000 hours |
| Cooling System | 135 mm fan |
| Features | Overheat protection, gold-plated terminals, over current protection, over voltage protection, overpower protection, undervoltage protection, short-circuit protection, Multi-GPU Technologies Supported, fluid dynamic bearing cooling fan, fully modular |
| Compliant Standards | TUV, BSMI, CB, CCC, RoHS, WEEE, cTUVus, REACH, EAC, ErP Lot 6 2013 Ready |
| Environmental Standards | Environmental Standards |
| ENERGY STAR | Yes |
| Manufacturer Warranty | Manufacturer Warranty |
| Service & Support | Limited warranty - 12 years |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 50 °C |
| Dimensions & Weight | Dimensions & Weight |
| Width | 15 cm |
| Depth | 21 cm |
| Height | 8.6 cm |
Features - Sea Sonic - PRIME-TX-1600-ATX30
More Details
Product Code
07:131995
EAN Code
4711173878018
Manufacturer
Sea Sonic
