Special Fetures
- SFX version 3.0 and ATX version 1.3 specification compliant
- Energy saving Power Factor Correction (PFC)
- One single independent 12 V rail
- High efficiency (82%) up to 30% less power consumption
- I/O short circuit - overload - and over current-protection
Product Specification
| Device Type | Power supply - Power Factor Correction (PFC) - internal |
| Specification Compliance | SFX12V 3.0 |
| PSU Form Factor | SFX |
| Power Device | |
| Input Voltage | AC 230 V |
| Input Voltage Range | AC 220 - 240 V |
| Frequency Required | 50 - 60 Hz |
| Input Connectors | 1 x power |
| Power Output Connectors Details | 1 x power 24 pin ATX with detachable 4 pin section <br /> 1 x power 4 pin ATX12V connector <br /> 4 x 4 PIN internal power <br /> 1 x 4 PIN mini-power connector <br /> 2 x 15 pin Serial ATA power |
| Power Capacity | 300 Watt |
| Miscellaneous | |
| Cables Included | Power cable - external |
| MTBF | 100,000 hours |
| Cooling System | 80 mm fan |
| Features | Over voltage protection, overload protection, short-circuit protection |
| Compliant Standards | TUV, RoHS |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 2 years |
| Environmental Parameters | |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 40 °C |
| Sound Emission | 21 dBA |
| Dimensions & Weight | |
| Width | 12.5 cm |
| Depth | 10 cm |
| Height | 6.4 cm |
Features - Spire - C7
More Details
Product Code
04:512013
EAN Code
6943051233161
Manufacturer
Spire
