StarTech.com 5-Port USB PCIe Card / 10Gbps USB 3.1 Gen 2 / 1x USB-C / 2x USB-A / 1x 2 Port IDC (Internal 5Gbps USB Header Expansion) | PEXUSB312A1C1H

PEXUSB312A1C1H
93.45
(111.21 inc. VAT)
Availability: 10 item(s)
Standard DeliveryStandard delivery within 4 to 8 business days.Express DeliveryExpress delivery within 2 to 3 business days.
Delivery
Payment options
Product CodeCB93544 EAN Code0065030888325 ManufacturerStarTech.com

Product Features

  • Work faster and prepare for the future
    This versatile PCI Express combo card leverages the performance potential of USB 3.2 Gen 2x1 (10Gbps) to help you work faster. The USB ports offer a data throughput of up to 10Gbps, so you can spend less time waiting for file transfers to complete or for access to your external peripherals.
  • Connect different types of USB devices
    Now you can easily add a variety of types and speeds (generations) of USB ports to your desktop or server, using a single adapter card. With a range of port types, the card lets you bridge the gap between devices that use different connectors. You can simultaneously connect and access USB Type-A and USB Type-C devices, while using only a single PCI Express expansion slot. By adding three types of USB ports in one combo card, you can free up space in your PC case, and eliminate the nuisance of having different cards for different USB devices.
  • Ideal for building or upgrading your computer
    With two internal motherboard-style headers, this dynamic USB 3.1 card is perfect for upgrading or building your own computer. If your existing headers are occupied, or if you don't have any motherboard headers, you can connect front panel hubs or card readers using this versatile alternative to costly motherboard or computer upgrades.
  • Connect your older USB devices
    Connecting your older peripherals isn't a problem. This 5-port USB 3.2 card is backward compatible with legacy USB 3.0, 2.0 and 1.1 devices, so you can eliminate the added expense and aggravation of purchasing new devices.

Special Features

  • Work faster and prepare for the future
  • Connect different types of USB devices
  • Ideal for building or upgrading your computer
  • Connect your older USB devices

Product Specification

Device Type USB adapter
Form Factor Plug-in card
Interface (Bus) Type PCI Express 3.0 x4
Networking Networking
Ports USB-C 3.1 Gen 2 x 2 + USB-C 3.2 Gen 2 x 1
Connectivity Technology Wired
Data Link Protocol USB 2.0, SuperSpeed USB 3.0, USB 3.1, USB 3.2 Gen 2, USB 3.2 Gen 1
Data Transfer Rate 10 Gbps
Features USB Attached SCSI Protocol (UASP)
Compliant Standards USB 2.0, USB 3.0, USB 3.1, USB 3.2 Gen 2, USB 3.2 Gen 1
Processor / Memory Processor / Memory
Processor ASMedia ASM1142
Expansion / Connectivity Expansion / Connectivity
Interfaces 2 x USB 3.1 Gen 2 - 9 pin USB Type A ¦ 1 x USB 3.2 Gen 2 - 24 pin USB-C ¦ 1 x SATA power - 15 pin Serial ATA power (internal) ¦ 1 x USB 3.0 - 20 pin IDC (internal)
Miscellaneous Miscellaneous
Included Accessories Low-profile bracket
MTBF 1,677,495 hours
Compliant Standards FCC, RoHS, WEEE, UASP (USB Attached SCSI Protocol)
Colour Red
Software / System Requirements Software / System Requirements
OS Required Microsoft Windows Server 2008 R2, Microsoft Windows Server 2012 R2, Microsoft Windows Server 2016, Apple macOS High Sierra 10.13, Apple macOS Mojave 10.14, Microsoft Windows Server 2019, Linux LTS versions only, Linux 3.5 or later, Apple macOS Catalina 10.15, Apple macOS Big Sur 11.0, Apple macOS Monterey 12.0, Microsoft Windows 7 / 8 / 8.1 / 10 / 11, Apple macOS Ventura 13.0
Dimensions & Weight Dimensions & Weight
Width 6.89 cm
Depth 10.2 cm
Height 1.44 cm
Weight 60 g
Dimensions & Weight (Shipping) Dimensions & Weight (Shipping)
Shipping Width 14.2 cm
Shipping Depth 17 cm
Shipping Height 3 cm
Shipping Weight 125 g
Manufacturer Warranty Manufacturer Warranty
Service & Support Limited warranty - 2 years
Environmental Parameters Environmental Parameters
Min Operating Temperature 0 °C
Max Operating Temperature 70 °C
Humidity Range Operating 15 - 90% (non-condensing)
