StarTech.com M.2 to U.3 Adapter / M.2 NVMe Card / PCIe 4.0 | 1M25-U3-M2-ADAPTER
1M25-U3-M2-ADAPTER
Find similar
Delivery
Payment options
Please sign in so that we can notify you about a reply
Product Features
- PCIe M.2 SSD to 2.5" U.3 adapter
Convert and connect a PCIe M.2 NVMe/AHCI SSD to a 2.5-inch form factor to install in U.3 drive bays/backplanes; Compatible with U.3 (SFF-TA-1001) host interfaces; M.2 to U.3 Adapter is TAA Compliant. - Full performance
Change the form factor of a 2242, 2260, or 2280 M.2 NVMe drive while preserving the read and write speeds; No chipset design ensures no loss in performance when adapting to 2.5-inch. - Hassle-free setup
M.2 to U.3 Host Adapter works with all operating systems including Windows, macOS, and Linux; M2 to U.3 Adapter requires no additional drivers or software; Includes drive and adapter mounting screws for an efficient installation. - Versatile M.2 NVMe support
Open frame design enables support for M.2 drives with larger heatsinks, and allows for better airflow; Supports PCIe 4.0 and lower drives; SFF-TA-1001 is not compatible with SATA/SAS/U.2 host controllers or SATA-based M.2 SSDs.
Special Features
- PCIe M.2 SSD to 2.5" U.3 adapter
- Full performance
- Hassle-free setup
- Versatile M.2 NVMe support
Product Specification
| Device Type | Interface adapter - external |
| Hard Drive Form Factor Compatibility | M.2 |
| Host Bus | U.3 |
| Colour | Red |
| Storage Controller | Storage Controller |
| Interface | M.2 NVMe Card / PCIe 4.0 (NVMe) |
| Supported Devices | Solid state drive |
| Max Storage Devices Qty | 1 |
| Expansion / Connectivity | Expansion / Connectivity |
| Bays | 1 x internal - M.2 2242/2260/2280 |
| Interfaces | 1 x M.2 Card - M.2 M key (internal) |
| Connections | 1 x U.3 NVMe - U.3 (SFF-TA-1001) |
| Miscellaneous | Miscellaneous |
| Features | S.M.A.R.T. support, supports NVM Express, 60 cycles insertion rating |
| Mounting Kit | Included |
| MTBF | 12,368,734 hours |
| Compliant Standards | FCC, RoHS, WEEE |
| Environmental Standards | Environmental Standards |
| TAA Compliant | Yes |
| Manufacturer Warranty | Manufacturer Warranty |
| Service & Support | Limited warranty - 2 years |
| Dimensions & Weight | Dimensions & Weight |
| Width | 7 cm |
| Depth | 10 cm |
| Height | 0.7 cm |
| Weight | 37 g |
| Dimensions & Weight (Shipping) | Dimensions & Weight (Shipping) |
| Shipping Width | 14.2 cm |
| Shipping Depth | 17.5 cm |
| Shipping Height | 3 cm |
| Shipping Weight | 100 g |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 50 °C |
| Humidity Range Operating | 15 - 90% RH |
Features - StarTech.com - 1M25-U3-M2-ADAPTER
More Details
Product Code
CI52689
EAN Code
0065030900744
Manufacturer
StarTech.com
