StarTech.com Mini Thunderbolt 3 Dock / MacBook Pro & Windows, Dual 4K 60Hz / Docking station / USB-C 3.1 / Thunderbolt 3 / 2 x HDMI / GigE | TB3DKM2HD
StarTech.com Mini Thunderbolt 3 Dock / MacBook Pro & Windows, Dual 4K 60Hz / Docking station / USB-C 3.1 / Thunderbolt 3 / 2 x HDMI / GigE | TB3DKM2HD
Description This Thunderbolt 3 docking station packs big performance into a cost-effective, compact mini dock, delivering essential connections for productivity. The bus-powered Thunderbolt 3 dock lets you connect to dual 4K HDMI displays, Gigabit Ethernet and two USB (Type-A) ports and for a flexible setup, the attached USB-C cable has an extended length of (7.9 in./ 20 cm).Great for editing 4K video or other Ultra HD tasks, this portable Thunderbolt 3 to HDMI dock supports 40Gbps of throughput and 4K resolution at 60Hz on dual HDMI monitors, through a single Thunderbolt 3 port. Run resource-demanding applications on two independent displays without draining system resources.Connect your laptop to 2x 4K HDMI displays (up to 4096 x 2160p @ 60Hz).Simply connect the TB3 dock to your laptop with included TB3 cable and start working immediately. No time-consuming driver installations are required.To enhance your productivity, the Gigabit Ethernet port (with PXE Boot and Wake-on-LAN support) ensures reliable wired network access. AUSB 3.0 Type-A port, with ample space around it, lets you connect a USB device, such as a flash drive, for easy file access. Connect another USB device using the USB 2.0 Type-A port. |
Product Specification
Product Type | Docking station |
Width | 6 cm |
Depth | 12 cm |
Height | 1.88 cm |
Weight | 145.8 g |
Enclosure Colour | Black & grey |
Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, USB 1.1, USB 2.0, USB 3.0, USB 3.1 |
Interfaces | 1 x USB-C 3.1 / Thunderbolt 3 - 24 pin USB-C ¦ 2 x display / video - HDMI - 19 pin HDMI Type A ¦ 1 x SuperSpeed USB 3.0 - 9 pin USB Type A ¦ 1 x USB 2.0 - 4 pin mini-USB Type A ¦ 1 x network - 10Base-T/100Base-TX/1000Base-T - RJ-45 |
Cables Included | 1 x Thunderbolt 3 / USB-C cable - integrated - 20 cm |
Features | USB powered, dual display support, Preboot Execution Environment (PXE) support, full duplex support, 4K Ultra HD, auto MDIX support |
Compliant Standards | FCC, RoHS, UASP (USB Attached SCSI Protocol) |
OS Required | Microsoft Windows 7 / 8 / 8.1 / 10, Apple MacOS X 10.12 - 10.13 |
Service & Support | Limited warranty - 3 years |
Shipping Weight | 268.2 g |
Min Operating Temperature | 5 °C |
Max Operating Temperature | 35 °C |
