Supermicro AOC-S3108L-H8IR-16DD / Storage controller (RAID) / 8 Channel / SATA 6Gb/s / SAS 12Gb/s low profile / 12 Gbit/s / RAID 0, 1, 5, 6, 10, 50, 60 / PCIe 3.0 | AOC-S3108L-H8IR-16DD
Please sign in so that we can notify you about a reply
Special Features
- LSI SAS 3108 8-port PCI-E SAS-3 controller
- 8-port (8 internal) 12Gb/s per port
- Supports RAID 0, 1, 5, 6, 10, 50, 60
- On board hardware IO processor
- 2GB 1866MHz DDR3 on-card cache
- Advanced array configuration and management utilities
- Automatically negotiates PCI-E link widths
- Power management support
- Supports 1.5, 3.0, 6.0 and 12Gb/s SAS and SATA data transfer rates
- Port independent auto-negotiation
- Supports SSP, SMP, STP and SATA protocols
Product Specification
| Device Type | Storage controller (RAID) - plug-in card - low profile |
| Host Bus | PCIe 3.0 |
| Storage Controller | Storage Controller |
| Interface | SATA 6Gb/s / SAS 12Gb/s |
| Data Transfer Rate | 12 Gbit/s |
| Buffer Size | 2 GB |
| Supported Devices | Hard drive, disk array (RAID) |
| Channel Qty | 8 |
| Max Storage Devices Qty | 16 |
| RAID Level | RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60 |
| Processor | LSI LSISAS3108 |
| Expansion / Connectivity | Expansion / Connectivity |
| Interfaces | SATA 6Gb/s / SAS 12Gb/s (internal) |
Features - SUPERMICRO - AOC-S3108L-H8IR-16DD
More Details
Product Code
03:155285
EAN Code
0672042188499
Manufacturer
SUPERMICRO
