Synology Disk Station DS3622XS+ / NAS server / 12 bays / SATA 6Gb/s / RAID 0, 1, 5, 6, 10, JBOD, RAID F1 / RAM 16 GB / Gigabit Ethernet / 10 Gigabit Ethernet / iSCSI support | DS3622XS+
Product Specification
| Device Type | NAS server |
| Host Connectivity | Gigabit Ethernet / 10 Gigabit Ethernet |
| Total Storage Capacity | 0 GB |
| Installed Devices / Modules Qty | 0 (installed) / 12 (max) |
| Width | 30 cm |
| Depth | 34 cm |
| Height | 27 cm |
| Weight | 9.8 kg |
| Built-in Devices | Led panel |
| Processors Installed | 1 x Intel Xeon D-1531 2.2 GHz |
| Number of Cores | 6-core |
| Max Supported Qty | 1 |
| Max Turbo Speed | 2.7 GHz |
| RAM | 16 GB (installed) / 48 GB (supported) - DDR4 |
| Type | RAID |
| Interface Type | SATA 6Gb/s |
| RAID Level | RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, JBOD, RAID F1 |
| Data Link Protocol | 10Mb LAN, 100Mb LAN, GigE, 10 GigE |
| Network / Transport Protocol | TCP/IP, PPTP, L2TP, iSCSI, SMTP, FTP, DNS, POP3, IMAP, SMB, NFS, SFTP, HTTP, HTTPs |
| Remote Management Protocol | SNMP, Telnet, HTTP, HTTPS, TFTP, SSH, SFTP |
| Network Services Compatibility | Microsoft Active Directory (AD), DNS, File Level Security (ACLs), Microsoft CIFS, FTP, Server Message Block (SMB), Apple File Protocol (AFP), HTTP, HTTPS, Web-based Distributed Authoring and Versioning (WebDAV), Calendaring Extensions to WebDAV (CalDAV), SFTP, Server Message Block 2.0 (SMB 2.0), Server Message Block 3.0 (SMB 3.0), Network File System v3 (NFS v3), Network File System v4 (NFS v4), Network File System v4.1 (NFS v4.1) |
| Features | Firewall protection, hardware encryption, LDAP support, wake on LAN (WOL), High Availability, backup server, download client, file sharing, event log, Access Control List (ACL) support, RADIUS support, iTunes server, FTP server, reset button, bandwidth control, surveillance station, PXE support, DNS server, DLNA Media Server, Apple Time Machine compatible, e-mail notification, cloud backup, VPN Server, Dropbox support, anti-virus protection, Link Aggregation, Photo album server, Google Drive support, Yandex Disk support, Microsoft OneDrive support, OpenStack compatible, file station, hubiC support, OpenStack Swift-compatible, WebDAV server support, Baidu cloud support, cloud station server, MailPlus server, Amazon S3 support, Rsync compatible, Alibaba Cloud OSS support, Backblaze B2 support, MegaDisk support, Tencent COS support |
| Encryption Algorithm | SSL, TLS, AES-NI |
| IP Cameras Supported | 75 |
| Compression Format | MJPEG, H.264, H.265 |
| Image Resolution | 1280x720, 1920x1080, 2048x1536, 2591x1944, 3840x2160 |
| Expansion Bays | 12 (total) / 12 (free) x hot-swap - 2.5" / 3.5" |
| Expansion Slots | 1 (total) / 1 (free) x PCI Express 3.0 x8 ¦ 4 (total) / 2 (free) x SO-DIMM 260-pin |
| Interfaces | 2 x USB 3.2 Gen 1 - Type A ¦ 2 x Ethernet 1000Base-T - RJ-45 ¦ 2 x Ethernet 10Gb - RJ-45 ¦ 2 x expansion port |
| Cables Included | 2 x network cable |
| Features | Wake on LAN, lockable, built-in 2 cooling fans, scheduled power on/off, reset button |
| Compliant Standards | VCCI, BSMI, FCC, RoHS, KC, EAC, RCM |
| Included Accessories | Accessory pack |
| Power Device | Internal power supply |
| Voltage Required | AC 100-240 V (50/60 Hz) |
| Power Provided | 550 Watt |
| Storage Operating System | Synology DiskStation Manager |
| Software Included | McAfee AntiVirus (Trial) |
| OS Required | Microsoft Windows 7 or later, Apple MacOS X 10.12 or later |
| Service & Support | Limited warranty - 5 years |
| Min Operating Temperature | 5 °C |
| Max Operating Temperature | 40 °C |
| Humidity Range Operating | 5 - 95% RH |
| Sound Emission | 25 dBA |
