Synology RackStation RS1619xs+ / NAS server / 4 bays / rack-mountable / SATA 6Gb/s / RAID 0, 1, 5, 6, 10, JBOD, RAID F1 / RAM 8 GB / Gigabit Ethernet / iSCSI support / 1U | RS1619XS+
Please sign in so that we can notify you about a reply
Synology RackStation RS1619xs+ / NAS server / 4 bays / rack-mountable / SATA 6Gb/s / RAID 0, 1, 5, 6, 10, JBOD, RAID F1 / RAM 8 GB / Gigabit Ethernet / iSCSI support / 1U | RS1619XS+
Product Specification
| Device Type | NAS server |
| Host Connectivity | Gigabit Ethernet |
| Enclosure Type | Rack-mountable - 1U |
| Total Storage Capacity | 0 GB |
| Max Supported Capacity | 56 TB |
| Installed Devices / Modules Qty | 0 (installed) / 4 (max) |
| Width | 48 cm |
| Depth | 51.86 cm |
| Height | 4.4 cm |
| Weight | 8.16 kg |
| Built-in Devices | Led panel |
| Processors Installed | 1 x Intel Xeon D-1527 2.2 GHz |
| Number of Cores | Quad-Core |
| Max Supported Qty | 1 |
| Max Turbo Speed | 2.7 GHz |
| RAM | 8 GB (installed) / 64 GB (supported) - DDR4 |
| Features | ECC |
| Type | RAID |
| Interface Type | SATA 6Gb/s |
| RAID Level | RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, JBOD, RAID F1 |
| Data Link Protocol | 10Mb LAN, 100Mb LAN, GigE |
| Network / Transport Protocol | TCP/IP, PPTP, L2TP, iSCSI, FTP, NFS |
| Remote Management Protocol | SNMP, Telnet, HTTPS, SSH |
| Network Services Compatibility | Microsoft Active Directory (AD), Microsoft CIFS, Network File System (NFS), FTP, Apple File Protocol (AFP), Web-based Distributed Authoring and Versioning (WebDAV), Calendaring Extensions to WebDAV (CalDAV) |
| Features | Firewall protection, hardware encryption, LDAP support, wake on LAN (WOL), IP address filtering, backup server, download client, anti-malware protection, event log, Access Control List (ACL) support, Samba support, FTP server, reset button, bandwidth control, surveillance station, PXE support, DLNA Media Server, cloud backup, VPN Server, Dropbox support, anti-virus protection, Google Drive support, Amazon Cloud Drive support, Yandex Disk support, Microsoft OneDrive support, hubiC support, OpenStack Swift-compatible, cloud station server, MailPlus server, Amazon S3 support |
| Encryption Algorithm | SSL, TLS, AES-NI |
| Compliant Standards | DLNA CERTIFIED |
| IP Cameras Supported | 75 |
| Compression Format | MJPEG, H.264, H.265 |
| Image Resolution | 1280x720, 1920x1080, 2048x1536, 2591x1944, 3840x2160 |
| Expansion Bays | 4 (total) / 4 (free) x hot-swap - 2.5" / 3.5" |
| Expansion Slots | 1 (total) / 1 (free) x PCI Express 3.0 x8 ¦ 4 (total) / 3 (free) x DIMM 288-pin ¦ 2 (total) / 2 (free) x M.2 |
| Interfaces | 4 x Ethernet 1000Base-T - RJ-45 ¦ 2 x USB 3.0 - Type A ¦ 1 x serial (management) - DB-9 |
| Features | Wake on LAN, built-in 2 cooling fans, scheduled power on/off |
| Compliant Standards | VCCI, BSMI, CCC, FCC, RoHS, KC, EAC, RCM |
| Included Accessories | Accessory pack |
| Power Device | Internal power supply |
| Installed Qty | 2 |
| Max Supported Qty | 2 |
| Power Redundancy | Yes |
| Power Redundancy Scheme | 1+1 |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Power Consumption Operational | 68.68 Watt |
| Power Provided | 150 Watt |
| Software Included | McAfee AntiVirus (Trial) |
| Service & Support | Limited warranty - 5 years |
| Min Operating Temperature | 5 °C |
| Max Operating Temperature | 35 °C |
| Humidity Range Operating | 5 - 95% |
| Sound Emission | 39.3 dBA |
Features - Synology - RS1619XS+
More Details
Product Code
03:130116
EAN Code
4711174723065
Manufacturer
Synology
