TP-Link Archer VR2100v V1 / Wireless router / DSL modem / 4-port switch / GigE / WAN ports: 2 / Wi-Fi 5 / DECT / Dual Band / VoIP phone adapter (DECT) | ARCHER VR2100V(DE)

Product Features
- Versatile connectivity
Archer VR2100v is built to connect you to the Internet, no matter your situation. The Ethernet WAN port supports wired connections to cable or fiber modems, letting you take full charge of its wireless capabilities as a router. In case your Internet goes down, attach a 3/4G adapter to the USB 3.0 port to serve as a backup option so you can get back online in no time. - Enjoy the network at full speed
Archer VR2100v makes full use of its dual band Wi-Fi abilities, reaching speeds of up to 1733 Mbps on the 5 GHz band and 300 Mbps on the 2.4 GHz band. Enjoy a total speed of up to 2.1 Gbps to eliminate latency, buffering, and lag from your HD streams and online games. Two dedicated Wi-Fi networks support more devices and reduce wireless interference to create stable connections. - Smart and Convenient telephony
Make your phone calls via Archer VR2100v's high-performance telephony system. Connect up to two analog phones with an HD-quality voice signal. With storage for up to 300 minutes of voice messages, never worry about missed phone calls or deleted messages again. - 4x4 MU-MIMO - efficient Wi-Fi for every device
MU-MIMO technology serves up to four devices at once, reducing wait time, increasing Wi-Fi throughput for every device, and making each stream more efficient. - Flexibly create a whole home Wi-Fi
OneMesh is a simple way to form a Mesh network with a single Wi-Fi name for seamless whole-home coverage. Just connect a OneMesh range extender to a OneMesh router. No more searching around for a stable connection. - Lightning-fast wired connections
One USB 3.0 port provides data transfers up to 10x faster than a traditional USB 2.0 port. Connect external storage devices and share files, photos, and videos at high-speed. 4x Gigabit LAN ports help wired devices achieve peak performance for HD streaming and gaming.
Special Features
- Super VDSL - the Super VDSL (VDSL2 Profile 35b) tech delivers Internet speeds of up to 350 Mbps
- Ultra-fast speed - surpasses the Wi-Fi speed limits of the previous generation, reaching up to 1733 Mbps on 5 GHz and 300 Mbps on 2.4 GHz
- HD telephony - supports up to two analog telephones or fax machines, as well as 300 minutes of voice mail storage
- MU-MIMO technology - simultaneously transfers data to multiple devices to reduce congestion and boost the average throughput
- Whole-home coverage with OneMesh - works with TP-Link OneMesh products to create a flexible and cost-efficient Mesh network
- Lightning-fast wired connection - USB 3.0 port and 4x Gigabit ports run up to 10x faster than the previous generation to unleash your home entertainment
Product Specification
Device Type | Wireless router - 4-port switch (integrated) |
Enclosure Type | Desktop |
Connectivity Technology | Wireless, wired |
Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, DECT, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac |
Frequency Band | 2.4 GHz / 5 GHz |
Performance | Maximum data rate (2.4 GHz): 300 Mbps ¦ Maximum data rate (5 GHz): 1733 Mbps |
Capacity | Maximum number of handsets: 6 ¦ IPSec VPN tunnels: 10 |
Network / Transport Protocol | PPTP, IPSec, FTP, DHCP, DNS, DDNS, RTP, SFTP, IPv4, IPv6 |
Routing Protocol | RIP-1, RIP-2, IGMPv2, IGMP, static IP routing, IGMPv3 |
Remote Management Protocol | SNMP 1, SNMP 2c, HTTP, HTTPS, CLI, TR-069, SFTP, DHCP |
Encryption Algorithm | 128-bit WEP, 64-bit WEP, SSL, WPA, WPA2, WPA-PSK, WPA2-PSK, WPS |
Wi-Fi Rating | AC2100 |
Features | NAT support, VPN support, Stateful Packet Inspection (SPI), ALG support, Asynchronous Transfer Mode (ATM), Wi-Fi Multimedia (WMM) support, Quality of Service (QoS), virtual server support, Wi-Fi Protected Setup (WPS), DHCP server, port forwarding, reset button, port triggering, DHCP relay, 3G/4G USB Dongle Support, DNS relay, DHCP client, SYN Flooding, Ping of Death, MU-MIMO technology, WDS bridge, LED on/off button, 4x4 MU-MIMO technology, Denial of Service (DoS) protection, DMZ support, 6KV lightning protection, Point-to-Point Protocol (PPP), OpenVPN client, IPTV support |
Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, UPnP, IEEE 802.11ac, RoHS |
Line Properties | Line Properties |
Framing Format | ANSI T1.413i2 |
Communications | Communications |
Type | DSL modem |
Digital Signaling Protocol | ADSL, VDSL, ADSL2, ADSL2+, VDSL2 |
Protocols & Specifications | ITU G.992.1 (G.DMT), ITU G.992.2 (G.Lite), ITU G.994.1 (G.hs), ITU G.992.3 (G.DMT.bis), ITU G.992.4 (G.lite.bis), ITU G.992.5 Annex M, ITU G.993.2, ITU G.992.5 Annex A, ITU G.992.5 Annex J, ITU G.998.4, ITU G.993.5, ITU G.995.11 |
Data Compression Protocol | G.726, G.722, G.729AB |
Max Transfer Rate | 350 Mbps |
IP Telephony | IP Telephony |
VoIP Functionality | VoIP phone adapter (DECT) |
VoIP Protocols | SIP, RTP |
Voice Codecs | G.722, G.729ab, G.726, G.711A/µ |
Telephony Interfaces | DECT |
IP Telephony Features | Call forwarding, call transfer |
Expansion / Connectivity | Expansion / Connectivity |
Interfaces | LAN: 3 x 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ WAN / LAN: 1 x 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ WAN: 1 x DSL - RJ-11 ¦ Phone line: 2 x VDSL2 / ADSL2+ - RJ-11 ¦ Phone line: 2 x ¦ USB 3.0: 1 x |
Aerial | Aerial |
Aerial | External and internal |
Antenna Qty | 4 |
Power | Power |
Power Device | External power adapter |
Miscellaneous | Miscellaneous |
Cables Included | 1 x network cable ¦ 1 x RJ-11 phone cable |
Software / System Requirements | Software / System Requirements |
OS Required | UNIX, Apple MacOS, Novell NetWare, Linux, Microsoft Windows 98SE/2000/NT/XP/Vista/7/8/8.1/10 |
Dimensions & Weight | Dimensions & Weight |
Width | 21.6 cm |
Depth | 16.37 cm |
Height | 3.68 cm |
Environmental Parameters | Environmental Parameters |
Min Operating Temperature | 0 °C |
Max Operating Temperature | 40 °C |
Humidity Range Operating | 10 - 90% (non-condensing) |
