TP-Link Omada EAP613 V1 / Radio access point / Wi-Fi 6 / 2.4 GHz, 5 GHz / cloud-managed / wall / ceiling mountable (pack of 5) | EAP613(5-PACK)
Please sign in so that we can notify you about a reply
Product Features
- Superior Wi-Fi 6 speeds
Upgrade to Wi-Fi 6 with speeds up to 1775 Mbps brings 50% faster speeds than Wi-Fi 5. Every application feels more fluid with drastically improved Wi-Fi speeds. - Auto channel selection and power adjustment to optimize overall performance
Provides powerful wireless performance while significantly reducing Wi-Fi interference by automatically adjusting the channel settings and transmission power levels of neighboring APs in the same network. - Easy deployment and higher performance by Omada mesh
With Mesh technology, Omada EAPs save you from extra wires by wirelessly extending your Wi-Fi signal further and more flexibly to hard-to-wire areas. - Always stay smooth with fast roaming
Ensures customers to enjoy uninterrupted streaming when moving around by switching clients automatically to the access points with the optimal signal. - Ultra-slim design brings more agility
Exceptional performance with compact design ensures simple Wi-Fi installation while saving space. The elegant appearance makes EAP613 perfectly blend into any modern office, hotel, classroom, or café.
Special Features
- Ultra-fast Wi-Fi 6 speeds - simultaneous 574 Mbps on 2.4 GHz and 1201 Mbps on 5 GHz totals 1775 Mbps Wi-Fi speeds
- High-efficiency Wi-Fi 6 - more connected devices can enjoy faster speeds
- Centralized cloud management - manage the whole network locally or from the cloud via web UI or Omada app
- Seamless roaming - even video streams and voice calls are unaffected as users move between locations
- Omada mesh - enables wireless connectivity between access points for extended range and flexible deployment
- PoE+ powered - supports DC, 802.3at PoE+, and Passive PoE for flexible installations
- Ultra-slim design - elegant design brings more agility
- Secure guest network - along with multiple authentication options (SMS/Voucher, etc.) and abundant wireless security technologies
Product Specification
| Packaged Quantity | 5 (specifications are for single item) |
| Device Type | Radio access point |
| Width | 16 cm |
| Depth | 16 cm |
| Height | 3.36 cm |
| Networking | Networking |
| Form Factor | Wall / ceiling mountable |
| Connectivity Technology | Wireless |
| Data Transfer Rate | 1775 Mbps |
| Line Coding Format | OFDM, 1024 QAM, OFDMA |
| Data Link Protocol | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, 802.11ax |
| Spread Spectrum Method | OFDMA |
| Remote Management Protocol | SNMP 1, SNMP 3, SNMP 2c, HTTP, HTTPS, SSH |
| Cloud-Managed | Yes |
| Frequency Band | 2.4 GHz, 5 GHz |
| Performance | Maximum data rate (2.4 GHz): 574 Mbps ¦ Maximum data rate (5 GHz): 1201 Mbps |
| Capacity | Maximum number of configured SSIDs: 16 |
| Status Indicators | Status |
| Features | VLAN support, Syslog support, E-mail alert, MAC address filtering, Mesh networking, Wi-Fi Multimedia (WMM) support, Access Control List (ACL) support, Quality of Service (QoS), reset button, rogue access point detection, Captive Portal, Transmit Power Control (TPC), MU-MIMO technology, beamforming technology, band steering, rate limit, Wireless Scheduler, Software Defined Networking (SDN), LED on/off button, Fast Roaming, seamless roaming, Airtime Fairness, Zero-touch provisioning (ZTP), schedule reboot, load balance network mode |
| Encryption Algorithm | WPA-Enterprise, WPA2-Enterprise, WPA3-Enterprise, WPA3-Personal, WPA2-Personal, WPA-Personal |
| Compliant Standards | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.1x, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax, Wi-Fi CERTIFIED 6 |
| Aerial | Aerial |
| Antenna | Internal |
| Directivity | Omni-directional |
| Expansion / Connectivity | Expansion / Connectivity |
| Interfaces | 1 x 1000Base-T (PoE+) - RJ-45 - 11 W |
| Miscellaneous | Miscellaneous |
| Included Accessories | Wall/ceiling mounting kit |
| Compliant Standards | FCC, RoHS |
| Power | Power |
| Power Over Ethernet (PoE) Supported | PoE+ |
| Power Device | External power adapter |
| Power Consumption Operational | 11 Watt |
| Software / System Requirements | Software / System Requirements |
| OS Required | Linux, Microsoft Windows XP / Vista / 7 / 8 / 10 |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 40 °C |
| Humidity Range Operating | 10 - 90% (non-condensing) |
Features - TP-LINK - EAP613(5-PACK)
More Details
Product Code
CG95297
EAN Code
4895252500523
Manufacturer
TP-LINK
