TP-Link VIGI NVR1008H-8MP V1 / NVR / 8 channels / networked / rack-mountable | VIGI NVR1008H-8MP
Please sign in so that we can notify you about a reply
Product Features
- 4K HDMI video output and 16MP decoding capacity
Sharp image definition up to 8MP and an 8-channel display ensure you capture every detail, from every angle. - Dedicated 8 PoE+ ports
Features 8x 10/100 Mbps PoE+ ports, the NVR supports up to 30 W on each PoE+ port. Designed to use a single Ethernet cable for both data and power transmission, it offers flexible installation to fit in various surveillance scenarios for small businesses, such as groceries, warehouses, restaurants, and financial institutions. - 8-channel simultaneous playback
Replay the feed from up to 8 cameras at the same time, increase replay speed, and find events in the video schedule to easily review footage. - More compression, more savings, same quality
Without using any extra bandwidth, your cameras transmit compressed crystal-clear video to save disk space, ease network loads, and reduce monitoring costs without sacrificing image quality. - Plug-and-Play
Allows new and unused VIGI IP cameras to be added automatically to the new NVR and activated instantly, making installation faster than ever before. - Flexible installation gives you more convenience
Choose the suitable installation method by simply housing your NVR on a rack, or placing it on or under a desk. - Two-way audio
With voice intercom support, carry two-way conversations while watching your feed from anywhere. Suitable for management.
Special Features
- 4K HDMI video output and 16MP decoding capacity
- Simplified deployment with PoE+
- 8-channel simultaneous playback
- H.265+
- Plug-and-Play
- 24/7 continuous recording
- Flexible installation
- Two-way audio
Product Specification
| Device Type | NVR - rack-mountable |
| Video Channels | 8 |
| IP Cameras Supported | 8 |
| Image Resolution | 1280x720, 1920x1080, 1024x768, 1680x1050, 1280x1024, 1440x900, 3840x2160 |
| Compression Format | H.264, H.265, H.264+, H.265+ |
| Package Content | Mouse, HDD screws |
| Compliant Standards | Plug and Play, IEEE 802.3af, IEEE 802.3at |
| Security DVR | Security DVR |
| Playback Search | Date / time, event |
| Networked | Yes |
| Features | 80Mbps Incoming Bandwidth, 60Mbps Outgoing Bandwidth |
| Hard Drive | Hard Drive |
| Quantity Supported | 1 |
| Interface | Serial ATA |
| Supported Max Total Capacity | 10 TB |
| Video Server | Video Server |
| Features | Two-way audio support |
| Networking | Networking |
| Network Interfaces | Ethernet 10Base-T/100Base-TX |
| Supported Protocols | DHCP, DNS, NTP, TCP/IP, UPnP |
| Features | ONVIF support, 113W PoE+ power budget |
| Connections | Connections |
| Video Input Ports | RJ-45 x 8 |
| Video Output Ports | HDMI x 1, VGA x 1 |
| Audio Input Ports | RCA x 1 |
| Audio Output Ports | RCA x 1 |
| Network Port | 10/100Base-T |
| Other Ports | USB 2.0 x 2 |
| Power | Power |
| Voltage | 53.5 V |
| Power Consumption | 4.82 Watt |
| Power Consumption Details | Without HDD |
| Dimensions & Weight | Dimensions & Weight |
| Width | 29.4 cm |
| Depth | 18 cm |
| Height | 4.4 cm |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | -10 °C |
| Max Operating Temperature | 55 °C |
Features - TP-LINK - VIGI NVR1008H-8MP
More Details
Product Code
CH12256
EAN Code
4897098688762
Manufacturer
TP-LINK
