TRENDnet TI-F10S30 / Fibre media converter / 100Mb LAN / 10Base-T, 100Base-FX, 100Base-TX / RJ-45 / SC single-mode / up to 30 km / 1310 nm | TI-F10S30
Please sign in so that we can notify you about a reply
Product Features
- Network ports
Features 10/100 Ethernet port and 100Base-FX SC-type fiber port. - Fiber
100Base-FX single mode fiber over long distances. - Extreme temperatures
Hardened converter is rated for a wide operating temperature range. - LED indicators
LED indicators confirm network connectivity.
Special Features
- Hardened compact housing
- 100Base-FX single mode fiber over long distances
- SC-type fiber port
- Extreme operating temperature range
- Overload current protection
Product Specification
| Device Type | Fibre media converter |
| Form Factor | DIN rail mountable |
| Networking | Networking |
| Connectivity Technology | Wired |
| Cabling Type | 10Base-T, 100Base-FX, 100Base-TX |
| Data Link Protocol | 10Mb LAN, 100Mb LAN |
| Optical Wave Length | 1310 nm |
| Max Transfer Distance | 30 km |
| Features | Auto-negotiation, half duplex mode, full duplex mode, Link Fault Pass Through function (LFP), wall mountable, over-current protection, built-in DIP switch, 8KV ESD Protector, 6KV Surge protection |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3x |
| Expansion / Connectivity | Expansion / Connectivity |
| Interfaces | 1 x Ethernet 1000Base-T - RJ-45 female ¦ 1 x Ethernet 100Base-FX - SC single-mode female x 2 |
| Miscellaneous | Miscellaneous |
| Included Accessories | DIN-rail mounting kit, wall mounting kit, removable terminal block |
| MTBF | 510,304 hours |
| Compliant Standards | FCC, IEC 60068-2-27, IEC 60068-2-32, IEC 60068-2-6, IP40 |
| Power | Power |
| Power Device | External power adapter |
| Power Consumption Operational | 1.92 Watt |
| Dimensions & Weight | Dimensions & Weight |
| Width | 6 cm |
| Depth | 5 cm |
| Height | 3.5 cm |
| Weight | 90 g |
| Manufacturer Warranty | Manufacturer Warranty |
| Service & Support | Limited warranty - 3 years |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | -40 °C |
| Max Operating Temperature | 75 °C |
| Humidity Range Operating | 0 - 95% (non-condensing) |
Features - Trendnet - TI-F10S30
More Details
Product Code
04:190433
EAN Code
0710931160468
Manufacturer
Trendnet
