Ubiquiti Nanobeam M5-16 / Wireless bridge / AirMax / 802.11a/n, AirMax / 5 GHz | NBE-M5-16
Ubiquiti Nanobeam M5-16 / Wireless bridge / AirMax / 802.11a/n, AirMax / 5 GHz | NBE-M5-16
Description Starting with the first-generation NanoBridge, Ubiquiti Networks pioneered the all-in-one design for an airMAX product functioning as a CPE (Customer Premises Equipment). Now Ubiquiti Networks launches the generation of CPE, the NanoBeam. The NanoBeam directs RF energy in a tighter beamwidth. With the focus in one direction, the NanoBeam blocks or spatially filters out noise, so noise immunity is improved. This feature is especially important in an area crowded with other RF signals of the same or similar frequency. Ubiquiti Nanobeam M5-16 / Wireless bridge / AirMax GHz | NBE-M5-16Special Features
Product features
|
Product Specification
Device Type | Wireless bridge |
Ruggedized Design | Outdoor |
Width | 14 cm |
Depth | 5.4 cm |
Height | 14 cm |
Weight | 320 g |
Processors Installed | 1 x Atheros MIPS 74KC 560 MHz |
Max Supported Qty | 1 |
RAM | 64 MB DDR2 SDRAM |
Flash Memory | 8 MB |
Form Factor | External |
Connectivity Technology | Wireless |
Data Link Protocol | IEEE 802.11a, IEEE 802.11n, AirMax |
Frequency Band | 5 GHz |
Status Indicators | Power, WLAN, LAN |
Features | Wall mountable, reset button, pole mountable |
Compliant Standards | IEEE 802.11a, IEEE 802.11n |
Antenna | Internal |
Antenna Qty | 1 |
Gain Level | 16 dBi |
Interfaces | 1 x 100Base-TX - RJ-45 |
Included Accessories | PoE injector |
Compliant Standards | ETSI, IC, FCC, RoHS, IEC 60068-2-6, IEC 60068-2-14, MIL-STD 810G 506.5, IEC 60068-2-11, MIL-STD 810G 509.5 |
Power Over Ethernet (PoE) Supported | PoE |
Power Device | External power adapter |
Power Consumption Operational | 6 Watt |
OS Provided | AirOS |
Min Operating Temperature | -40 °C |
Max Operating Temperature | 70 °C |
Humidity Range Operating | 5 - 95% (non-condensing) |
