Ubiquiti NanoStation M2 / Radio access point / AirMax / AirMax / 2.4 GHz | NSM2

NSM2
98.58
(117.31 inc. VAT)
Availability: 17 item(s)
Standard DeliveryStandard delivery within 4 to 8 business days.
Find similar
Delivery
Payment options
Product Code04:171500 EAN Code810354022517 ManufacturerUbiquiti

Ubiquiti NanoStation M2 / Radio access point / AirMax / AirMax / 2.4 GHz | NSM2

Description

Ubiquiti Networks set the bar for the world's first low-cost and efficient broadband Customer Premises Equipment (CPE) with the original NanoStation. The NanoStationM and NanoStationlocoM take the same concept to the future with sleek and elegant form factors, along with integrated airMAX (MIMO TDMA protocol) technology. The low cost, high performance, and small form factor of NanoStationM and NanoStationlocoM make them extremely versatile and economical to deploy.



Ubiquiti NanoStation M2 / Radio access point / AirMax / AirMax / 2.4 GHz | NSM2

Special Features

  • Utilize airMAX Technology
  • Dual Ethernet Connectivity

Product features

  • Utilize airMAX Technology
    Unlike standard Wi-Fi protocol, Ubiquiti's Time Division Multiple Access (TDMA) airMAX protocol allows each client to send and receive data using pre-designated time slots scheduled by an intelligent AP controller. This "time slot" method eliminates hidden node collisions and maximizes airtime efficiency. It provides many magnitudes of performance improvements in latency, throughput, and scalability compared to all other outdoor systems in its class.
  • Dual Ethernet Connectivity
    The NanoStationM provides a secondary Ethernet port with software-enabled PoE output for seamless IP video integration.

Product Specification

Device Type Radio access point
Ruggedized Design Outdoor
Width 8 cm
Depth 3.1 cm
Height 29.4 cm
Weight 400 g
Processors Installed 1 x Atheros MIPS 24KC 400 MHz
Max Supported Qty 1
RAM 32 MB SDRAM
Flash Memory 8 MB
Form Factor External
Connectivity Technology Wireless
Data Transfer Rate 150 Mbps
Data Link Protocol AirMax
Frequency Band 2.4 GHz
Features MIMO technology, Quality of Service (QoS), pole mountable
Compliant Standards IEEE 802.3af
Antenna Internal
Gain Level 11 dBi
Interfaces 1 x 100Base-TX - RJ-45 ¦ 1 x 100Base-TX (PoE) - RJ-45
Included Accessories Pole mount
Compliant Standards FCC Part 15.247, RSS-210, IC, RoHS, ETSI 300 019
Power Over Ethernet (PoE) Supported PoE
OS Provided AirOS
Min Operating Temperature -30 °C
Max Operating Temperature 75 °C
Humidity Range Operating 5 - 95%

Features - Ubiquiti - NSM2

More Details
Product Code
04:171500
EAN Code
810354022517
Manufacturer
Ubiquiti
