WD Blue SA510 WDS100T3B0B / SSD / 1 TB / internal / M.2 2280 / SATA 6Gb/s / blue | WDS100T3B0B
Please sign in so that we can notify you about a reply
Product Specification
| Device Type | Solid state drive - internal |
| Capacity | 1 TB |
| Form Factor | M.2 2280 |
| Interface | SATA 6Gb/s |
| Width | 22 mm |
| Depth | 80 mm |
| Height | 2.38 mm |
| Weight | 4.8 g |
| Performance | Performance |
| SSD Endurance | 400 TB |
| Drive Transfer Rate | 600 MBps (external) |
| Internal Data Rate | 560 MBps (read) / 520 MBps (write) |
| 4KB Random Read | 90000 IOPS |
| 4KB Random Write | 82000 IOPS |
| Reliability | Reliability |
| MTBF | 1,750,000 hours |
| Expansion & Connectivity | Expansion & Connectivity |
| Interfaces | 1 x SATA 6 Gb/s |
| Compatible Bay | M.2 2280 |
| Power | Power |
| Power Consumption | 60 mW (active) ¦ 1800 mW (read) ¦ 2000 mW (write) ¦ 36 mW (sleep) ¦ 12 mW (DevSleep) |
| Software & System Requirements | Software & System Requirements |
| Software Included | Acronis True Image, Dropbox Professional (free for 3 months) |
| Miscellaneous | Miscellaneous |
| Compliant Standards | UL, TUV, VCCI, BSMI, FCC, KC, Morocco |
| Enclosure Colour | Blue |
| Manufacturer Warranty | Manufacturer Warranty |
| Service & Support | Limited warranty - 5 years |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 70 °C |
| Shock Tolerance (operating) | 1500 g @ 0.5 ms half-sine |
| Vibration Tolerance (operating) | 5 gRMS @ 10-2000 Hz |
| Vibration Tolerance (non-operating) | 4.9 gRMS @ 7-800 Hz |
Features - Western Digital - WDS100T3B0B
Form Factor
- 2.5"
- Internal
Capacity
1TB
Interface
- M.2
More Details
Product Code
07:126394
EAN Code
0718037884707
Manufacturer
Western Digital
