ZOTAC ZBOX / Barebone / mini PC / 1 x Core i5 13400 / 2.5 GHz / RAM 0 GB / GeForce RTX 4060 / Gigabit Ethernet, 2.5 Gigabit Ethernet, Bluetooth 5.2, IEEE 802.11ax (Wi-Fi 6) WLAN: / 802.11a/b/g/n/ac/ax, Bluetooth 5.2 | ZBOX-ERP54060W-BE
Please sign in so that we can notify you about a reply
Product Features
- Efficient connectivity
With a variety of interface options including 3 DisplayPort, 2 HDMI, and Thunderbolt 4, this ZOTAC ZBOX ensures seamless connectivity for all your peripherals and displays. - Advanced cooling
The built-in air cooling solution keeps the system running smoothly, even under heavy loads, ensuring reliable performance without overheating. - Powerful performance
Equipped with a 10-core Intel Core i5-13400 processor and NVIDIA GeForce RTX 4060 graphics, this mini PC delivers exceptional computing power and stunning visuals for gaming and professional tasks. - High-speed networking
Featuring Killer Wi-Fi 6 AX1650 and dual Ethernet ports, including a 2.5 Gigabit Ethernet port, the ZOTAC ZBOX offers fast and reliable network connections for uninterrupted streaming and gaming. - Expandable storage
With support for M.2 cards and a 2.5" internal expansion bay, users have the flexibility to increase storage capacity as needed, making it easy to store large files and applications.
Special Features
- 10-core Intel Core i5-13400 processor for high-performance multitasking
- NVIDIA GeForce RTX 4060 graphics for immersive gaming and professional work
- Killer Wi-Fi 6 AX1650 and dual Ethernet ports for fast, reliable networking
- Supports up to 4 monitors with DisplayPort and HDMI, enhancing productivity
- 80 PLUS Titanium certified 500 W power supply for efficient energy use
Product Specification
| Type | PC barebone |
| Product Form Factor | Mini PC |
| Built-in Devices | Air cooling solution |
| Processor / Chipset | Processor / Chipset |
| CPU | Intel Core i5 (13th Gen) 13400 |
| Clock Speed | 2.5 GHz (P-core) / 1.8 GHz (E-core) |
| Max Turbo Speed | 4.6 GHz (P-core) / 3.3 GHz (E-core) |
| Number of Cores | 10-core |
| CPU Qty | 1 |
| Max CPU Qty | 1 |
| Processor Main Features | Intel Smart Cache |
| Cache Memory | Cache Memory |
| Installed Size | 20 MB |
| Cache Per Processor | 20 MB |
| RAM | RAM |
| Installed Size | 0 GB / 64 GB (max) |
| Technology | DDR5 SDRAM |
| Effective Memory Speed | 4800 MHz |
| Rated Memory Speed | 4800 MHz |
| Form Factor | SO-DIMM 262-pin |
| Slots | 2 (Total) / 0 (empty) |
| Hard Drive | Hard Drive |
| Type | No HDD |
| Storage Controller | Storage Controller |
| Type | SATA |
| Controller Interface Type | SATA 6Gb/s |
| Channel Qty | 1 |
| Optical Storage | Optical Storage |
| Type | No optical drive |
| Card Reader | Card Reader |
| Type | 3 in 1 card reader |
| Supported Flash Memory Cards | SD Memory Card, SDHC Memory Card, SDXC UHS-II Memory Card |
| Monitor | Monitor |
| Monitor Type | None. |
| Graphics Controller | Graphics Controller |
| Multi-GPU Configuration | 1 single GPU card / integrated GPU |
| Graphics Processor | NVIDIA GeForce RTX 4060 / Intel UHD Graphics 730 |
| Video Memory | 8 GB GDDR6 SDRAM |
| Video Interfaces | HDMI, DisplayPort |
| Max Monitors Supported | 4 |
| Audio Output | Audio Output |
| Sound Output Mode | Stereo |
| Networking | Networking |
| Ethernet Ports | 1 x 2.5 Gigabit Ethernet, 1 x Gigabit Ethernet |
| Wireless LAN Supported | Yes |
| Wireless NIC | Killer Wi-Fi 6 AX1650 |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, 2.5 Gigabit Ethernet, Bluetooth 5.2, IEEE 802.11ax (Wi-Fi 6) |
| Expansion / Connectivity | Expansion / Connectivity |
| Bays | 1 (total) / 1 (free) x internal 2.5" |
| Slots | 1 (total) / 1 (free) x M.2 Card - 2242/2280/22110 (PCIe 4.0 x4 mode) ¦ 1 (total) / 1 (free) x M.2 Card - 2242/2280 (SATA/PCIe 4.0 x4 (NVMe)) |
| Interfaces | 3 x DisplayPort (3 rear) ¦ 2 x HDMI (2 rear) ¦ 1 x LAN (Gigabit Ethernet) - RJ-45 (1 rear) ¦ 1 x LAN (2.5Gigabit Ethernet) - RJ-45 (1 rear) ¦ 1 x headphones/microphone - mini-jack (1 front) ¦ 3 x USB 3.0 (1 front, 2 rear) ¦ 1 x USB-C 3.0 (1 front) ¦ 1 x Thunderbolt 4 (1 rear) ¦ 4 x USB 3.1 (4 rear) |
| Miscellaneous | Miscellaneous |
| Included Accessories | USB flash drive, 2 x aerials |
| Theft/Intrusion Protection | Security lock slot (cable lock sold separately) |
| Security Slot Type | Kensington security slot |
| Power | Power |
| Device Type | Power supply |
| Power Provided | 500 Watt |
| 80 PLUS Certification | 80 PLUS Titanium |
| Operating System / Software | Operating System / Software |
| OS Provided | No operating system |
| OS Certified | Windows 11 |
| Dimensions & Weight | Dimensions & Weight |
| Width | 12.6 cm |
| Depth | 26.55 cm |
| Height | 24.9 cm |
| Dimensions & Weight (Shipping) | Dimensions & Weight (Shipping) |
| Shipping Width | 32.7 cm |
| Shipping Depth | 44 cm |
| Shipping Height | 20.5 cm |
Features - ZOTAC - ZBOX-ERP54060W-BE
CPU Type
- Intel Core i5
More Details
Product Code
04:458561
EAN Code
4895173628412
Manufacturer
ZOTAC
