Product Features
- Speedy Gigabit performance - built for SMBs
Featuring Gigabit performance that's 10 times faster than Fast Ethernet, the GS1900 is a series of switches with full non-blocking bandwidth of up to 1 Gbps per port. An ideal upgrade from an unmanaged switch, it's a great choice for SMBs that want to enjoy high-speed business network applications at full wired non-blocking speed. - Set-up guidance
The default PoE consumption mode delivers only the actual power required by your networked devices, reserves the rest and optimizes its power budget. That means a single switch can power more APs, IP cameras and VoIP phones, ensuring a better ROI for your business. The switch supports the IEEE 802.3at providing a maximum of 30W per port and 130W total budget. - Web managed with advanced features
Designed to support advanced features like VLAN, enhanced Quality of Service, IGMP Snooping, Link Aggregation (LAG), IPv6 and Dos prevention, this switch helps you segregate and prioritize traffic streams and keep up with your network as it grows. - Compact size, silent operation
GS1900-8 comes with desktop dimensions and fanless design. The slim and silent Switch can perfectly blend into any working environment without disturbing fan noises. - Plug into the power of the Zyxel One network
The Zyxel One Network (ZON) Utility is a unified installation tool to discover and configure Zyxel Switches, WLAN and Gateways in the network. Users can easily maintain the network in a single platform. ZON Utility is a free of charge tool which has been downloaded by over 45,000 users to date. - Versatility to meet different business needs
The GS1900 comes in a range of options from 8- to 48-port, PoE or SFP uplinks, desktop or rack-mounting option for effortless setup in versatile business environment.
Special Features
- Fast networking performance with 24 Gigabit Ethernet ports
- GS1900-24E comes with desk top dimensions and fanless design
- The intuitive web-based setup wizard enables simple and fast configuration and management, even for non-technical staff
- Advanced features like VLAN, QoS, IGMP Snooping, Link Aggregation (LAG), IPv6 and DoS prevention enable better security and management
Product Specification
| Device Type | Switch - 24 ports - smart |
| Enclosure Type | Rack-mountable, wall-mountable |
| Subtype | Gigabit Ethernet |
| Ports | 24 x 10/100/1000 |
| Performance | Switching capacity: 48 Gbps ¦ Forwarding performance: 35.7 Mpps |
| MAC Address Table Size | 8K entries |
| Jumbo Frame Support | 9KB |
| Routing Protocol | IGMPv2, IGMP, IGMPv3, MSTP, RSTP, STP |
| Remote Management Protocol | SNMP 1, SNMP 2, RMON 1, RMON 2, RMON 3, RMON 9, SNMP 3, ICMP |
| Encryption Algorithm | SSL |
| Authentication Method | RADIUS, TACACS+ |
| Features | Flow control, auto-uplink (auto MDI/MDI-X), IGMP snooping, Syslog support, DoS attack prevention, port mirroring, store and forward, IPv6 support, half duplex mode, full duplex mode, firmware upgradable, LACP support, Port Security, DHCP client, Strict Priority Queuing (SPQ), Neighbor Discovery Protocol (NDP), Class of Service (CoS), 525KB packet buffer, Storm Control, CPU protection, Management Information Base (MIB) II, dual image support, Voice VLAN, VLAN management, LLDP-MED, Guest VLAN, Energy-Efficient Ethernet (EEE), Weighted Round Robin (WRR), VLAN Tagging, TOS Precedence |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3az |
| Status Indicators | Power, system, link/activity |
| Expansion / Connectivity | Expansion / Connectivity |
| Interfaces | 24 x 1000Base-T RJ-45 |
| Power | Power |
| Power Device | Internal power supply |
| Voltage Required | AC 100-240 V (50/60 Hz) |
| Miscellaneous | Miscellaneous |
| Included Accessories | Rack mount kit, wall mounting kit |
| Rack Mounting Kit | Included |
| MTBF | 524,139 hours |
| Compliant Standards | FCC, RoHS, BSMI CNS 13438, BSMI CNS 14336-1, EN 62368-1, RCM Class A |
| Localisation | Europe |
| Dimensions & Weight | Dimensions & Weight |
| Width | 26.7 cm |
| Depth | 16.2 cm |
| Height | 4.2 cm |
| Weight | 1.56 kg |
| Dimensions & Weight (Shipping) | Dimensions & Weight (Shipping) |
| Shipping Width | 32.5 cm |
| Shipping Depth | 22.3 cm |
| Shipping Height | 7.1 cm |
| Shipping Weight | 2.05 kg |
| Manufacturer Warranty | Manufacturer Warranty |
| Service & Support | Limited warranty - lifetime |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 40 °C |
| Humidity Range Operating | 10 - 95% (non-condensing) |
| Min Storage Temperature | -40 °C |
| Max Storage Temperature | 70 °C |
| Humidity Range Storage | 10 - 95% (non-condensing) |
| Compatibility Information | Compatibility Information |
| Designed For | Zyxel USG Flex 100 |
Features - Zyxel - GS1900-24E-EU0103F
General
24-Port
More Details
Product Code
CD66984
EAN Code
4718937621132
Manufacturer
Zyxel
