Zyxel GS1900-24EP / Switch / smart / 24 x 10/100/1000 (12 PoE) / rack-mountable, wall-mountable / PoE (130 W) | GS1900-24EP-EU0101F

Zyxel GS1900-24EP / Switch / smart / 24 x 10/100/1000 (12 PoE) / rack-mountable, wall-mountable / PoE (130 W) | GS1900-24EP-EU0101F
Description
The GS1900 series includes both fan-less and built-in smart fan models. The smart fan is designed to automatically adjust speed based on device temperature. You can barely hear the sound while the switch is operating. It is ideal for your office environment.It comes with default PoE consumption mode which delivers only the actual power required by your networked devices, reserves the rest, and optimizes its power budget. That means a single switch can power more APs, IP cameras, and VoIP phones, ensuring a better ROI for your business. All of them support the IEEE 802.3at providing a maximum of 30W per port.The GS1900 is a series of switches with full non-blocking bandwidth. An ideal upgrade from an unmanaged switch, it's a great choice for SMBs that want to enjoy high-speed business network applications at full wired non-blocking speed.The smart managed GS1900 series switch feature with a web-based interface to manage advanced functions such as VLAN, QoS, IGMP snooping, link aggregation, IPv6, and Dos prevention easily. Also, the user-friendly wizard helps to walk through setup, configuration, and even advanced settings quickly.
Zyxel GS1900-24EP / Switch | GS1900-24EP-EU0101F
Special Features
- Near silent operation
- Intelligent PoE+ powers more devices
- Speedy Gigabit performance - built for SMBs
- Easy and intuitive management
Product features
- Near silent operation
The GS1900 series includes both fan-less and built-in smart fan models. The smart fan is designed to automatically adjust speed based on device temperature. You can barely hear the sound while the switch is operating. It is ideal for your office environment. - Intelligent PoE+ powers more devices
It comes with default PoE consumption mode which delivers only the actual power required by your networked devices, reserves the rest, and optimizes its power budget. That means a single switch can power more APs, IP cameras, and VoIP phones, ensuring a better ROI for your business. All of them support the IEEE 802.3at providing a maximum of 30W per port. - Speedy Gigabit performance - built for SMBs
The GS1900 is a series of switches with full non-blocking bandwidth. An ideal upgrade from an unmanaged switch, it's a great choice for SMBs that want to enjoy high-speed business network applications at full wired non-blocking speed. - Easy and intuitive management
The smart managed GS1900 series switch feature with a web-based interface to manage advanced functions such as VLAN, QoS, IGMP snooping, link aggregation, IPv6, and DoS prevention easily. Also, the user-friendly wizard helps to walk through setup, configuration, and even advanced settings quickly.
Product Specification
Device Type | Switch - 24 ports - smart |
Enclosure Type | Rack-mountable, wall-mountable |
Subtype | Gigabit Ethernet |
Ports | 24 x 10/100/1000 (12 PoE) |
Power Over Ethernet (PoE) | PoE |
PoE Budget | 130 W |
Performance | Switching capacity: 48 Gbps ¦ Forwarding performance: 35.7 Mpps |
MAC Address Table Size | 8K entries |
Jumbo Frame Support | 9KB |
Routing Protocol | IGMPv2, IGMP, IGMPv3 |
Remote Management Protocol | SNMP 1, SNMP 2, RMON 1, RMON 2, RMON 3, RMON 9, SNMP 3 |
Encryption Algorithm | SSL |
Authentication Method | RADIUS, TACACS+ |
Features | Flow control, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, Syslog support, DoS attack prevention, Weighted Round Robin (WRR) queuing, store and forward, IPv6 support, Quality of Service (QoS), fanless, LACP support, LLDP support, Port Security, Energy Efficient Ethernet, Management Information Base (MIB), Strict Priority Queuing (SPQ), Class of Service (CoS), tagged VLAN, per port bandwidth control, 525KB packet buffer |
Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.3az |
Status Indicators | Power, system, link/activity |
Interfaces | 12 x 1000Base-T RJ-45 ¦ 12 x 1000Base-T RJ-45 PoE |
Power Device | Internal power supply |
Voltage Required | AC 120/230 V (50/60 Hz) |
Power Consumption Operational | 166.5 Watt |
Rack Mounting Kit | Included |
MTBF | 910,015 hours |
Compliant Standards | FCC Class B certified, C-Tick Class B, RoHS, EN 60950-1, BSMI CNS 13438, BSMI CNS 14336 |
Localisation | Europe |
Width | 33 cm |
Depth | 23 cm |
Height | 4.4 cm |
Weight | 2.48 kg |
Shipping Width | 38.9 cm |
Shipping Depth | 33.7 cm |
Shipping Height | 7.9 cm |
Shipping Weight | 3.87 kg |
Service & Support | Limited warranty - lifetime |
Min Operating Temperature | 0 °C |
Max Operating Temperature | 50 °C |
Humidity Range Operating | 10 - 95% (non-condensing) |
Min Storage Temperature | -40 °C |
Max Storage Temperature | 70 °C |
