Zyxel GS2220-10HP / Switch / Managed / 8 x 10/100/1000 (PoE+) + 2 x combo Gigabit SFP / rack-mountable, wall-mountable / PoE+ (180 W) | GS2220-10HP-EU0101F
Please sign in so that we can notify you about a reply
Zyxel GS2220-10HP / Switch / Managed / 8 x 10/100/1000 (PoE+) + 2 x combo Gigabit SFP / rack-mountable, wall-mountable / PoE+ (180 W) | GS2220-10HP-EU0101F
Description
Zyxel's GS2220 Series are fully featured Layer 2 Gigabit access switches designed to meet converged data, video and voice networking needs. On top of the fully manageable L2 features set comes with the state-of-the-art Zyxel NebulaFlex Pro technology for cloud manageability.
Zyxel GS2220-10HP / Switch | GS2220-10HP-EU0101F
Special Features
- Agile traffic control for converged networking applications
- Experience whisper-silent operations
- Power your devices with efficiency and energy-saving
Product features
- Agile traffic control for converged networking applications
The GS2220 Series has a rich Layer 2 feature set that can shape the traffic for diverse VoIP, video conference and IPTV deployments. Advanced traffic control features of the GS2220 Series such as L2 multicast, IGMP snooping, multicast VLAN registration (MVR) provide hotels, businesses, and educational institutions greater agility and more effective traffic management for the converged applications. - Experience whisper-silent operations
The smart fan is designed to automatically adjust speeds based on the device temperature, offering near silence while the GS2220 Series is in operation. Ideal for your office environment no matter if it's on the desktop or mounted on a rack. - Power your devices with efficiency and energy-saving
The GS2220 Series PoE switches support 802.3at PoE Plus standards to offer 30-watt per port along with maximum 375-watt high-power budget to meet the needs from power-hungry devices. The default consumption mode allows delivery of only the actual power required by devices connected to the switch for better business ROI.
Product Specification
| Device Type | Switch - 8 ports - Managed |
| Enclosure Type | Rack-mountable, wall-mountable |
| Subtype | Gigabit Ethernet |
| Ports | 8 x 10/100/1000 (PoE+) + 2 x combo Gigabit SFP |
| Power Over Ethernet (PoE) | PoE+ |
| PoE Budget | 180 W |
| Performance | Switching capacity: 20 Gbps ¦ Forwarding rate: 15 Mpps ¦ Packet buffer size: 1.5 MB |
| MAC Address Table Size | 16K entries |
| Routing Protocol | IGMPv2, IGMP, IGMPv3, static IPv4 routing, static IPv6 routing, MLD, MSTP, RSTP, STP |
| Remote Management Protocol | SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, TFTP, SSH-2, CLI, NTP, ICMP, DHCP, RSTP, TACACS+, RADIUS |
| Encryption Algorithm | SSL |
| Authentication Method | RADIUS, TACACS+, Secure Shell v.2 (SSH2) |
| Features | Flow control, IGMP snooping, Syslog support, port mirroring, IP address filtering, ZyXEL iStacking Technology, sFlow, Quality of Service (QoS), MLD snooping, LACP support, LLDP support, DHCP relay, Port Security, DHCP client, Management Information Base (MIB), Multicast VLAN Registration (MVR), port isolation, Class of Service (CoS), Generic VLAN Registration Protocol (GVRP), cloud managed, DiffServ Code Point (DSCP) support, ErrDisable Recovery, IP source guard, ARP inspection, dual image support, Root Guard, Loop Guard, LLDP-MED, Energy-Efficient Ethernet (EEE), VLAN Tagging, MRSTP |
| Compliant Standards | IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.3az |
| RAM | 256 MB |
| Flash Memory | 32 MB |
| Status Indicators | Status |
| Interfaces | 10 x 1000Base-T RJ-45 PoE+ ¦ 2 x 1000Base-X SFP ¦ 1 x serial (RS-232) |
| Power Device | Internal power supply |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Power Consumption Operational | 210.8 Watt |
| Included Accessories | Wall mounting kit |
| Rack Mounting Kit | Included |
| MTBF | 587,477 hours |
| Compliant Standards | BSMI, RoHS, FCC Part 15 A, LVD, EMC Class A |
| Localisation | Europe |
| Width | 26.7 cm |
| Depth | 16.2 cm |
| Height | 4.4 cm |
| Weight | 1.8 kg |
| Shipping Width | 37.5 cm |
| Shipping Depth | 23.5 cm |
| Shipping Height | 6.1 cm |
| Shipping Weight | 2.7 kg |
| Service & Support | Limited warranty - lifetime |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 50 °C |
| Humidity Range Operating | 10 - 95% |
