Zyxel NR5101 / Wireless router / WWAN / GigE, LTE / LTE, 802.11a/b/g/n/ac/ax / Dual Band / 3G, 4G, 5G | NR5101-EU01V1F
Product Features
- Lightning-fast Internet connectivity
The Zyxel NR5101 has 5G NR DL speeds higher than 5 Gbps and 4G LTE DL speeds of up to 2 Gbps. The wide spectrum bandwidth accelerates Internet speeds and reduces network latency for premium and time-sensitive connectivity services. With the high-speed 5G NR service you are able to fulfill the worldwide market requirements of mobile broadband access services. - Wi-Fi 6 (11ax) technology for superior performance and coverage
Compliant with the latest Wi-Fi 6 (802.11ax) standard, the Zyxel NR5101 offers speeds of up to 1.8 Gbps with 2x2 UL/DL MU-MIMO. The uplink MU-MIMO, Orthogonal Frequency Division Multiple Access (OFDMA) and beamforming technologies empower the NR5101 to deliver premium speed for multi-streaming data access and optimal Wi-Fi experience without dead zones. - Strengthen your competitive edge with Fixed Wireless Access (FWA)
Deploying NR5101 as part of FWA allows you to extend your 5G service coverage into subscribers' homes and workplaces without extra wire infrastructure. This secures the TCOs and increases business revenue by supporting a larger number of subscribers with a premium fixed-grade connection. - Remote management and upgrade
Through the LTE radio interface, NR5101 supports TR-069, remote GUI, and FTP to be fully configurable. Firmware Over-The-Air (FOTA) support enables remote firmware upgrades and troubleshooting through events triggered by the operators.
Special Features
- Lightning-fast Internet connectivity
- Wi-Fi 6 (11ax) technology for superior performance and coverage
- Strengthen your competitive edge with Fixed Wireless Access (FWA)
- Remote management and upgrade
Product Specification
Device Type | Wireless router |
Enclosure Type | Desktop |
Connectivity Technology | Wireless, wired |
Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6), LTE |
Frequency Band | 2.4 GHz / 5 GHz |
Data Transfer Rate | 5 Gbps |
Network / Transport Protocol | FTP, IPv4, IPv6 |
Routing Protocol | RIP-1, RIP-2 |
Remote Management Protocol | Telnet, HTTP, TR-069 |
Encryption Algorithm | WPA, WPA2, WPA2-Personal |
Features | NAT support, NAPT support, VLAN support, Stateful Packet Inspection (SPI), DoS attack prevention, ALG support, MAC address filtering, VPN passthrough, URL filtering, IP address filtering, firmware upgradable, Wi-Fi Multimedia (WMM) support, Auto Channel Select (ACS), Wi-Fi Protected Setup (WPS), DHCP server, hidden SSID, port forwarding, reset button, port triggering, Firmware Over-the-Air (FOTA), VoIP support, Internet Control Message Protocol (ICMP), dual band, router mode, DMZ support, DynDNS, bridge mode, 4x4 MIMO technology, MQTT support |
Compliant Standards | Wi-Fi Protected Setup, UPnP, G.726, G.722, G.711 (µ-law), G.168, Wi-Fi CERTIFIED 6, RoHS, WEEE, HSF, Directive 94/62/EC, G.711 A-Law, IP68 Certified, 3GPP Release 15, GR 487 issue 4 (2013) |
Status Indicators | Power, Internet, Wi-Fi |
Line Properties | Line Properties |
Line Coding Format | 64 QAM, 256 QAM, QPSK, 16 QAM |
Communications | Communications |
Type | Wireless cellular modem |
Mobile Communication Protocol | 5G NR |
Generation | 3G, 4G, 5G |
Cellular Band | LTE B3, LTE B7, LTE B20, LTE B1, LTE B26, LTE B5, LTE B39, LTE B28, LTE B8, LTE B40, LTE B41, LTE B38, LTE B18, LTE B19, LTE B32, LTE B42, 5G n78, 5G n1, 5G n3, 5G n5, 5G n7, 5G n8, 5G n20, 5G n28, 5G n40, 5G n41, 5G n77, LTE B34, 5G n38 |
Max Transfer Rate | 5 Gbps |
IP Telephony | IP Telephony |
IP Telephony Features | RFC 3261 support |
Expansion / Connectivity | Expansion / Connectivity |
Interfaces | LAN: 1 x 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ WAN / LAN: 1 x 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ USB 2.0: 1 x ¦ Antenna: 2 x SMA |
Expansion Slots | 1 (total) / 1 (free) x Micro-SIM |
Aerial | Aerial |
Aerial | Internal |
Antenna Qty | 6 |
Power | Power |
Power Device | External power adapter |
Miscellaneous | Miscellaneous |
Cables Included | 1 x network cable - 1.8 m |
Dimensions & Weight | Dimensions & Weight |
Width | 10 cm |
Depth | 10 cm |
Height | 20.5 cm |
Weight | 600 g |
Dimensions & Weight (Shipping) | Dimensions & Weight (Shipping) |
Shipping Width | 24.7 cm |
Shipping Depth | 17 cm |
Shipping Height | 12 cm |
Shipping Weight | 1.6 kg |
Environmental Parameters | Environmental Parameters |
Min Operating Temperature | 0 °C |
Max Operating Temperature | 40 °C |
Humidity Range Operating | 10 - 90% (non-condensing) |
