Zyxel NR7101 / Wireless router / WWAN / GigE, LTE / 802.11b/g/n, LTE / 2.4 GHz / 3G, 4G, 5G / wall-mountable, pole-mountable | NR7101-EU01V1F
Product Features
- Extremely fast
Speed is everything in business. Technology progresses at record pace, so companies must do whatever it takes to stay relevant. NR7101 has up to 5 Gbps data rates, which can provide your business an advantage by being faster than others. Take part in it know! - Be the pioneer
Feeling the need to increase bandwidth and network speed at office? Want to help manufacturing production operations become more flexible and efficient with better precision and lower costs than human inspection? Get a head start on smart office or industry 5.0, it's time to upgrade to 5G and empower your future. NR7101 is poised to be your backbone of your network to pave the way for your future business success. - Better signal, work wonders
Six 10 dBi long range directional antennas are built into the NR7101 to provide a focused networking coverage. Experience better, stronger signal strength and enhanced signal quality of 5G network for faster speed. Grab the NR7101, it's efficient and can work wonders! - Strong backbone, stronger connection
NR7101 has industrial-grade components with outdoor-friendly design making it possible to work in harsh environment conditions where desirable signal strength is difficult to achieve or having weather challenges including strong winds and rainstorms. NR7101 guarantees high-quality connections and a longer device life, which supports your business deployment in wide territorial scopes. - Network slicing, tailor your network
NR7101 is interoperable with both Standalone (SA) and Non-Standalone (NSA) deployments. Under SA mode, NR7101 can support network slicing function with tailored network capabilities that are essential to fulfill different business needs, like dealing complex environments with massed wired and wireless networks for separate factory and office connections, and handling of multiple-node Wi-Fi infrastructure, which can be unstable. Customize network via NR7101 to keep ahead of industry and to ensure success! - Efficient and precise installation
A remote and simple DIY for own installation costs less than fiber as no electrician is required! To find the best signal spot for installation, you just need to use a smartphone or tablet to connect to NR7101's Wi-Fi network and follow its configuration instruction on the "Zyxel LTE Ally" app.
Special Features
- Extremely fast
- Be the pioneer
- Better signal, work wonders
- Strong backbone, stronger connection
- Network slicing, tailor your network
- Efficient and precise installation
Product Specification
Device Type | Wireless router |
Enclosure Type | Wall-mountable, pole-mountable |
Connectivity Technology | Wireless, wired |
Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, LTE |
Frequency Band | 2.4 GHz |
Data Transfer Rate | 5 Gbps |
Network / Transport Protocol | FTP, IPv4, IPv6 |
Routing Protocol | RIP-1, RIP-2 |
Remote Management Protocol | HTTP, TR-069 |
Features | NAT support, NAPT support, VLAN support, Stateful Packet Inspection (SPI), DoS attack prevention, ALG support, MAC address filtering, VPN passthrough, URL filtering, IP address filtering, firmware upgradable, DHCP server, hidden SSID, port forwarding, reset button, port triggering, Firmware Over-the-Air (FOTA), Internet Control Message Protocol (ICMP), router mode, DMZ support, DynDNS, bridge mode, 6KV lightning protection, 4x4 MIMO technology, MQTT support |
Compliant Standards | IEEE 802.3af, IEEE 802.3at, UPnP, RoHS, WEEE, HSF, Directive 94/62/EC, IP68 Certified, 3GPP Release 15, GR 487 issue 4 (2013) |
Status Indicators | Power, Internet, Wi-Fi |
Line Properties | Line Properties |
Line Coding Format | 64 QAM, 256 QAM, QPSK, 16 QAM |
Communications | Communications |
Type | Wireless cellular modem |
Mobile Communication Protocol | 5G NR |
Generation | 3G, 4G, 5G |
Cellular Band | LTE B3, LTE B7, LTE B20, LTE B1, LTE B26, LTE B5, LTE B39, LTE B28, LTE B8, LTE B40, LTE B41, LTE B38, LTE B18, LTE B19, LTE B32, LTE B42, 5G n78, 5G n1, 5G n3, 5G n5, 5G n7, 5G n8, 5G n20, 5G n28, 5G n40, 5G n41, 5G n77, LTE B34, 5G n38 |
Max Transfer Rate | 5 Gbps |
Expansion / Connectivity | Expansion / Connectivity |
Interfaces | 1 x 10Base-T/100Base-TX/1000Base-T (PoE) - RJ-45 |
Expansion Slots | 2 (total) / 2 (free) x Micro-SIM |
Aerial | Aerial |
Aerial | Internal |
Antenna Qty | 6 |
Power | Power |
Power Device | Power injector |
Power Consumption Operational | 16 Watt |
Miscellaneous | Miscellaneous |
Cables Included | 1 x network cable - 1.8 m |
Mounting Kit | Included |
Dimensions & Weight | Dimensions & Weight |
Width | 25.5 cm |
Depth | 25.6 cm |
Height | 5.8 cm |
Weight | 1.143 kg |
Dimensions & Weight (Shipping) | Dimensions & Weight (Shipping) |
Shipping Width | 28 cm |
Shipping Depth | 42 cm |
Shipping Height | 10.8 cm |
Shipping Weight | 2.818 kg |
Environmental Parameters | Environmental Parameters |
Min Operating Temperature | -40 °C |
Max Operating Temperature | 60 °C |
Humidity Range Operating | 5 - 95% (non-condensing) |
