BUFFALO TeraStation 5400 / NAS server / 4 bays / 4 TB / SATA 3Gb/s / HDD 1 TB x 4 / RAID 0, 1, 5, 6, 10, JBOD / Gigabit Ethernet / iSCSI | TS5400DWR0404-EU
BUFFALO TeraStation 5400 / NAS server / 4 bays / 4 TB / SATA 3Gb/s / HDD 1 TB x 4 / RAID 0, 1, 5, 6, 10, JBOD / Gigabit Ethernet / iSCSI | TS5400DWR0404-EU
Description TeraStation 5400 is a high performance 4-drive network storage solution ideal for businesses and demanding users requiring a reliable RAID based NAS and iSCSI storage solution for larger networks and business critical applications. With the powerful Intel Atom processor, and fully populated with high-reliability WD Red hard drives, the TeraStation 5400 provides exceptional performance during file transfers and everyday NAS functions: experience maximum network throughput while a replication job runs in the background, network surveillance video is recording from multiple IP cameras and remote users are accessing content. Special Features
Product features
|
Product Specification
Device Type | NAS server |
Host Connectivity | Gigabit Ethernet |
Total Storage Capacity | 4 TB |
Installed Devices / Modules Qty | 4 (installed) / 4 (max) |
Width | 17 cm |
Depth | 23.1 cm |
Height | 21.6 cm |
Weight | 8 kg |
Built-in Devices | Status LCD |
Processors Installed | 1 x Intel Atom D2550 1.86 GHz |
Number of Cores | Dual-Core |
Max Supported Qty | 1 |
RAM Installed | 2 GB DDR3 |
Type | RAID |
Interface Type | SATA 3Gb/s |
RAID Level | RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, JBOD |
Type | HDD - hot-swap |
Capacity | 4 x 1 TB |
Interface Type | SATA 3Gb/s |
Data Link Protocol | 10Mb LAN, 100Mb LAN, GigE |
Network / Transport Protocol | TCP/IP |
Remote Management Protocol | SNMP, HTTP, HTTPS |
Network Services Compatibility | Microsoft CIFS, Network File System (NFS), FTP, Server Message Block (SMB), Apple File Protocol (AFP), HTTP, HTTPS |
Features | LDAP support, print server, DFS support, FTP server, Buffalo Web Access, BitTorrent Client, DLNA Media Server, Apple Time Machine compatible, NTP time synchronisation, SFTP server |
Expansion Bays | 4 (total) / 0 (free) x hot-swap |
Interfaces | 2 x Ethernet 1000Base-T - RJ-45 ¦ 2 x USB 2.0 - Type A ¦ 3 x USB 3.0 - Type A ¦ 1 x serial - DB-9 |
Features | Wake on LAN, UPS support, device-to-device data replication |
Power Device | X internal power supply |
Voltage Required | AC 120/230 V (50/60 Hz) |
Power Consumption Operational | 96 Watt |
Storage Operating System | Linux |
Software Included | NovaBACKUP Business Essentials (10 licences), SoleraTec Phoenix RSM (1 license), Buffalo Surveillance Server |
OS Required | Microsoft Windows 2000 Server, Microsoft Windows 2000 / XP, Microsoft Windows Server 2003, Microsoft Windows XP Media Center Edition 2004, Microsoft Windows XP Media Center Edition 2005, Microsoft Windows Server 2008 R2, Microsoft Windows Server 2003 R2, Microsoft Windows Server 2008, Microsoft Windows Vista (32/64 bits), Microsoft Windows 7 (32/64 bits), Windows 8 (32/64 bits), Apple MacOS X 10.4 - 10.9 |
Service & Support | Limited warranty - 3 years |
Min Operating Temperature | 5 °C |
Max Operating Temperature | 35 °C |
Humidity Range Operating | 20 - 80% (non-condensing) |
- Ethernet
- iSCSI
