Chieftec TASK Series TPS-600S - Power supply (internal) - ATX12V 2.3/ EPS12V/ PS/2 - 80 PLUS Bronze - AC 100-240 V - 600 Watt - active PFC | TPS-600S
Chieftec TASK Series TPS-600S - Power supply (internal) - ATX12V 2.3/ EPS12V/ PS/2 - 80 PLUS Bronze - AC 100-240 V - 600 Watt - active PFC | TPS-600S
€81.4 inc. VAT
TPS-600S
Product Code07:135279
ManufacturerChieftec
Find similar
Delivery
Payment options
Συνδεθείτε για να μπορέσουμε να σας ειδοποιήσουμε σχετικά με μια απάντηση
Product Specification
| Device Type | Power supply - active Power Factor Correction (PFC) - internal |
| Specification Compliance | ATX12V 2.3/ EPS12V/ PS/2 |
| PSU Form Factor | ATX |
| Power Device | |
| Input Voltage | AC 100-240 V |
| Frequency Required | 47 - 63 Hz |
| Power Output Connectors Details | 1 x power 24 pin ATX with detachable 4 pin section ¦ 1 x power 8 pin EPS12V with detachable 4 pin ATX12V section ¦ 5 x 15 pin Serial ATA power ¦ 2 x 8 pin PCI Express power with detachable 2 pin section ¦ 3 x 4 PIN internal power |
| Output Voltage | +3.3, +5, ±12 V |
| Power Capacity | 600 Watt |
| Output Current | +5V - 17 A ¦ +3.3V - 19 A ¦ +12V1 - 46 A ¦ -12V - 0.3 A ¦ +5VSB - 2.5 A |
| Power Factor (PF) | 0.9 |
| 80 PLUS Certification | 80 PLUS Bronze |
| Miscellaneous | |
| Cooling System | 120 mm fan |
| Features | Overheat protection, over voltage protection, overpower protection, undervoltage protection, short-circuit protection, Automatic Fanspeed Control (AFC) |
| Compliant Standards | CB, FCC, RoHS, WEEE, ERP, EAC, Interseroh, TUV Rheinland |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 2 years |
| Dimensions & Weight | |
| Weight | 1.67 kg |
| Dimensions & Weight (Shipping) | |
| Shipping Weight | 2.08 kg |
