Cisco Catalyst 8500L-8S4X / Switch / 4 x 1 Gigabit / 10 Gigabit SFP+ + 8 x 1000Base-T / rack-mountable | C8500L-8S4X
C8500L-8S4X
Find similar
Delivery
Payment options
Συνδεθείτε για να μπορέσουμε να σας ειδοποιήσουμε σχετικά με μια απάντηση
Product Features
- High-performance control plane
CPU with multiple cores allocated to control plane with 16 GB memory default for high-speed control plane processes. - Flash storage
Default eUSB for storage for additional storage on the platform. - Power supply redundancy
High-efficiency dual power supplies by default for power supply redundancy.
Special Features
- High-performance control plane
- Flash storage
- Power supply redundancy
Product Specification
| Device Type | Switch - 12 ports |
| Enclosure Type | Rack-mountable 1U |
| Subtype | 10 Gigabit Ethernet |
| Ports | 4 x 1 Gigabit / 10 Gigabit SFP+ + 8 x 1000Base-T |
| Performance | SD-WAN IPsec throughput (1400Bytes, clear text): 19 Gbps ¦ SD-WAN IPsec throughput (IMIX, clear text): 8.6 Gbps ¦ IPv4 forwarding throughput (1400-byte packet size): 20 Gbps ¦ IPsec throughput (1400Bytes, clear text): 19 Gbps |
| Capacity | SD-WAN overlay tunnels scale: 8000 ¦ IPsec SVTI tunnels: 4000 ¦ ACLs per system: 4000 ¦ Access Control Entries (ACEs) per system (IPv4): 50000 ¦ IPv4 routes: 3500000 ¦ IPv6 routes: 2200000 ¦ Queues: 16000 ¦ NAT sessions: 2000000 ¦ Firewall sessions: 2000000 ¦ Virtual Routing and Forwarding (VRF) entries: 8000 |
| Routing Protocol | OSPF, IS-IS, RIP-1, RIP-2, BGP, EIGRP, HSRP, DVMRP, VRRP, PIM-SM, static IP routing, IGMPv3, GRE, OSPFv3, PIM-SSM, policy-based routing (PBR), MPLS, Bidirectional Forwarding Detection (BFD), RSVP, LISP |
| Remote Management Protocol | SNMP, SSH, CLI, SCP, NETCONF, NTP, DHCP, IPv4, IPv6, RADIUS, OMP |
| Encryption Algorithm | DES, Triple DES, SHA, MD5, IKE, TLS, PKI, 128-bit AES, 256-bit AES, DTLS, 1024-bit RSA, 2048-bit RSA, 256-bit SHA, 512-bit SHA, 748-bit RSA, 384-bit SHA, ECDSA 256-bit, ECDSA 384-bit |
| Authentication Method | Secure Shell (SSH), RADIUS |
| Features | Firewall protection, NAT support, VPN support, VLAN support, Syslog support, Class-Based Weighted Fair Queuing (CBWFQ), Weighted Random Early Detection (WRED), Access Control List (ACL) support, Quality of Service (QoS), DHCP server, DHCP relay, NTP server, DHCP client, Virtual Routing and Forwarding (VRF), Forward Error Correction (FEC), IPFIX, Flexible NetFlow (FNF), MACsec support, Application Visibility and Control (AVC), TrustSec support, Authentication, Authorization and Accounting (AAA), DNS client, IP Security (IPSec) support, Encapsulated Remote SPAN (ERSPAN), Embedded Event Manager (EEM), Ethernet Virtual Connections (EVC), Cisco IOS IP Service-Level Agreements (IPSLA), Network-Based Application Recognition (NBAR), L2TP support, Point-to-Point Protocol (PPP), High-Level Data Link Control (HDLC), Multilink Point-to-Point Protocol (MLPPP), Performance Routing (PfR), SD-WAN support, Application Aware Routing (AAR), DNS support, Secure Unique Device Identification (SUDI) |
| Compliant Standards | IEEE 802.1Q, IEEE 802.3ah, IEEE 802.1ag |
| RAM | 16 GB |
| Built-in Devices | 32 GB SSD |
| Expansion / Connectivity | Expansion / Connectivity |
| Interfaces | 4 x 1/10GBase-X SFP+ ¦ 8 x 1000Base-T RJ-45 ¦ 1 x management RJ-45 ¦ 1 x USB 3.0 Type A ¦ 1 x mini-USB Type B |
| Power | Power |
| Power Device | Internal power supply |
| Max Supported Qty | 2 |
| Power Redundancy | Optional |
| Miscellaneous | Miscellaneous |
| MTBF | 240,200 hours |
| Compliant Standards | EN 61000-3-2, EN55022, IEC 61000-3-2, IEC 61000-3-3, EN 61000-3-3, EN55024, CISPR 22, EN50082-1, EN 61000-6-1, AS/NZS 60950-1, ICES-003 Class A, UL 60950-1, IEC 60950-1, EN 60950-1, GB 4943, GR-1089-CORE, VCCI Class A, GR-63-CORE, FCC CFR47 Part 15 A, CNS 13438 Class A, EN 300 386, KN35, IEC/EN 61000-4-3, IEC/EN 61000-4-4, IEC/EN 61000-4-5, IEC/EN 61000-4-6, AS/NZS CISPR 32 Class A, KN32 Class A, IEC/EN 61000-4-11, IEC/EN 61000-4-2, EN 55032 Class A, EN 55032, CISPR 32 Class A, CAN/CSA-C22.2 No. 60950-1, EN 55035 |
| Dimensions & Weight | Dimensions & Weight |
| Width | 44.5 cm |
| Depth | 41.3 cm |
| Height | 4.39 cm |
| Weight | 7.7 kg |
| Manufacturer Warranty | Manufacturer Warranty |
| Service & Support | Limited warranty - advance hardware replacement - 90 days - response time: 10 days |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 40 °C |
| Humidity Range Operating | 10 - 85% (non-condensing) |
| Min Storage Temperature | -40 °C |
| Max Storage Temperature | 70 °C |
| Humidity Range Storage | 5 - 95% (non-condensing) |
Χαρακτηριστικά
Product Code
CA96818
EAN Code
0889728322713
Manufacturer
Cisco
