Extreme Networks ExtremeSwitching 5420 Series 5420F-16MW-32P-4XE - Switch - L3 - Managed - 16 x 100/1000/2.5G (PoE++) + 32 x 10/100/1000 (PoE+) + 4 x 1 Gigabit / 10 Gigabit SFP+ (uplink) + 2 x SFP-DD (stackable) - rack-mountable - PoE++ (1862 W) | 5420F-1
5420F-16MW-32P-4XE
Find similar
Delivery
Payment options
Συνδεθείτε για να μπορέσουμε να σας ειδοποιήσουμε σχετικά με μια απάντηση
Special Fetures
- High-performance, feature-rich fixed-form switch for enterprise edge deployments
- Universal hardware platform providing end-to-end network segmentation
- 48-port model with Gigabit and Multi-Gigabit Ethernet connectivity
- MACsec on 10/100/1000 access and uplink ports for secure link encryption
- Layer 2/Layer 3 Fabric services for secure network segmentation and automation
- Non-blocking, wire-speed design
Product Specification
| Device Type | Switch - 48 ports - L3 - Managed |
| Enclosure Type | Rack-mountable |
| Subtype | Gigabit Ethernet |
| Ports | 16 x 100/1000/2.5G (PoE++) + 32 x 10/100/1000 (PoE+) + 4 x 1 Gigabit / 10 Gigabit SFP+ (uplink) + 2 x SFP-DD (stackable) |
| Power Over Ethernet (PoE) | PoE++ |
| PoE Budget | 1862 W |
| Performance | Aggregate bandwidth: 304 Gbps ¦ Frame rate: 226.2 Mpps |
| Max Units In A Stack | 8 |
| Remote Management Protocol | CLI |
| Encryption Algorithm | 128-bit AES, 256-bit AES |
| Features | Auto-sensing per device, half duplex mode, full duplex mode, MACsec support, LRM optics support |
| Compliant Standards | IEEE 802.1ae, IEEE 802.3at, IEEE 802.3bt |
| Expansion / Connectivity | |
| Interfaces | 16 x 100/1000/2.5G RJ-45 PoE++ - 90 W ¦ 32 x 10/100/1000 Base-T RJ-45 PoE+ - 30 W ¦ 4 x 1/10GBase-X SFP+ uplink ¦ 2 x network stack device SFP-DD ¦ 1 x serial (console) RJ-45 ¦ 1 x management (Gigabit LAN) RJ-45 ¦ 2 x USB ¦ 1 x console (micro-USB) |
| Power | |
| Power Device | Internal power supply |
| Installed Qty | 1 |
| Max Supported Qty | 2 |
| Power Redundancy | Optional |
| Power Provided | 1200 Watt |
| Voltage Required | AC 100-120/200-240 V |
| Software / System Requirements | |
| Software Included | Base Software License, ExtremeCloud IQ Pilot (1 year) |
| Dimensions & Weight | |
| Width | 44.1 cm |
| Depth | 33 cm |
| Height | 4.4 cm |
| Weight | 5.3 kg |
General
16-Port
Χαρακτηριστικά
Product Code
CA83423
EAN Code
0644728051977
Manufacturer
Extreme Networks
Δεν βρέθηκαν δημοσιεύσεις
