Gigabyte GA-Z270N-WIFI / 1.0 / motherboard / mini ITX / LGA1151 Socket / Z270 / USB 3.1 Gen1, USB-C Gen1 / Bluetooth, 2 x Gigabit LAN, Wi-Fi / onboard graphics (CPU required) / HD Audio (8-channel) | GA-Z270N-WIFI
|
Special Features
|
Product Specification
| Product Type | Motherboard - mini ITX |
| Chipset Type | Intel Z270 Express |
| Processor Socket | LGA1151 Socket |
| Max Processors Qty | 1 |
| Compatible Processors | Pentium, Celeron, Core i5, Core i3, Core i7 (supports 6th and 7th Generation Intel Core i3 / i5 / i7 / Pentium / Celeron) |
| Max Size | 32 GB |
| Technology | DDR4 |
| Bus Clock | 2133 MHz, 2800 MHz (O.C.), 2666 MHz (O.C.), 2400 MHz (O.C.), 3000 MHz (O.C.), 3200 MHz (O.C.), 3300 MHz (O.C.), 3400 MHz (O.C.), 3333 MHz (O.C.), 3466 MHz (O.C.), 3733 MHz (O.C.), 3600 MHz (O.C.), 3800 MHz (O.C.), 3666 MHz (O.C.), 3866 MHz (O.C.) |
| Supported RAM Integrity Check | Non-ECC, ECC |
| Registered or Buffered | Unbuffered |
| Features | Dual channel memory architecture, Intel Extreme Memory Profiles (XMP) |
| Max Allocated RAM Size | 1 GB |
| Type | HD Audio (8-channel) |
| Audio Codec | Realtek ALC1220 |
| Compliant Standards | High Definition Audio |
| Network Interfaces | Bluetooth, 2 x Gigabit Ethernet, 802.11a/b/g/n/ac |
| Expansion Slots | 1 x CPU ¦ 2 x DIMM 288-pin ¦ 1 x PCIe 3.0 x16 ¦ 1 x M.2 socket |
| Storage Interfaces | SATA-600 -connectors: 6 x 7pin Serial ATA - 6 devices - RAID 0 / RAID 1 / RAID 10 / RAID 5 ¦ SATA-600 / PCIe 3.0 -connectors: 1 x M.2 |
| Interfaces | 1 x DVI-D ¦ 2 x HDMI ¦ 2 x LAN (Gigabit Ethernet) ¦ 1 x TOSLINK ¦ 1 x audio line-out - mini-jack ¦ 1 x audio line-in - mini-jack ¦ 1 x microphone - mini-jack ¦ 1 x audio line-out (rear) - mini-jack ¦ 1 x audio line-out (center/subwoofer) - mini-jack ¦ 1 x USB-C Gen1 ¦ 4 x USB 3.1 Gen1 ¦ 1 x PS/2 keyboard / mouse |
| Internal Interfaces | 2 x USB 2.0 - header ¦ 2 x USB 3.1 Gen1 - header ¦ 1 x speaker - header ¦ 1 x SPDIF out - header ¦ 1 x audio - header |
| Power Connectors | 4-pin ATX12V connector, 24-pin main power connector |
| BIOS Type | AMI |
| BIOS Features | WfM 2.0 support, UEFI BIOS, SMBIOS 2.7 support, DMI 2.7 support, ACPI 5.0 support, Dual BIOS |
| Hardware Monitoring | CPU core temperature, chassis temperature, CPU fan tachometer, chassis fan tachometer, system voltage, CPU overheating protection |
| Hardware Features | Q-Flash, AutoGreen, Intel Extreme Memory Profile (XMP) support, 15µ Gold Contact, On/Off Charge, Easy RAID Installer, 3TB+ Unlock, Black Solid Capacitors, Clear CMOS Button, Game Boost, Ultra Durable PCIe Metal Shielding, GIGABYTE Double Locking Bracket, Anti-Sulfur Design, Intel Optane Memory Ready, GIGABYTE Smart Fan 5 |
| Software Included | Norton Internet Security, @BIOS, EasyTune, Cloud Station, Xpress Install, GIGABYTE USB Blocker, GIGABYTE App Center, cFosSpeed, Smart TimeLock, GIGABYTE Fast Boot, GIGABYTE V-Tuner, GIGABYTE Smart Keyboard, GIGABYTE Smart Backup, GIGABYTE Smart Fan 5, GIGABYTE 3D OSD |
| Compliant Standards | Plug and Play |
| Width | 17 cm |
| Depth | 17 cm |
Χαρακτηριστικά
Product Code
03:214530
EAN Code
4719331847302
Manufacturer
GigaByte
