NETGEAR ProSAFE XS712T / V2 / switch / L2+ / smart / 12 x 10GBase-T + 2 x shared 10 Gigabit SFP+ / rack-mountable | XS712T-200NES

Μάρκα: NetGear

ΚΩΔΙΚΟΣ (SKU):

XS712T-200NES

€893.60

€1,063.38 με Φ.Π.Α.

Μη Διαθέσιμο

Στα αγαπημένα Κάνε μια ερώτηση

Product Code0714305 EAN Code0606449129311 ManufacturerNetGear

Find similar

Delivery

Payment options

Προδιαγραφές
Χαρακτηριστικά

NETGEAR ProSAFE XS712T / V2 / switch / L2+ / smart / 12 x 10GBase-T + 2 x shared 10 Gigabit SFP+ / rack-mountable | XS712T-200NES

Description

The NETGEAR XS712Tv2 10-Gigabit Ethernet Smart Managed Pro Switch brings the second generation of 10-Gigabit Copper switching to SMBs. The XS712Tv2 is a powerful Smart Managed Switch that includes 12 ports of 10-Gigabit connectivity (12 copper with 2 shared combo copper/SFP+ Fiber ports). NETGEAR 10-Gigabit Smart Managed Pro Switches are purposely designed as a cost-effective way to provide 10G connections to 10G-capable servers and NAS (Network Attached Storage) systems. Advanced features include Layer 3 static routing, IPv6, DiffServ QoS, LACP link aggregation and Spanning Tree.

Special Features

Smart Managed Pro switch with 12 ports 10-Gigabit Ethernet
12 x 10-Gigabit Copper with 2 x shared (combo) 10-Gigabit SFP+ ports for servers and storage
Non-blocking 240Gbps fabric for all the connectivity you want without congestion and in full duplex mode
Easy-to-use Web browser-based management GUI (no need for an IT expert or a complicated user manual)
Advanced Smart features include Layer 3 static routing, LACP bonding, ACLs, STP and SNMP
LIFETIME Limited Warranty ' Includes LIFETIME Next Business Day Replacement, LIFETIME Technical Chat online support, and 90 days free Technical Phone support

Product Specification

Device Type	Switch - 12 ports - L2+ - smart
Enclosure Type	Rack-mountable 1U
Subtype	10 Gigabit Ethernet
Ports	12 x 10GBase-T + 2 x shared 10 Gigabit SFP+
Performance	Switching fabric bandwidth: 240 Gbps ¦ Forwarding performance (64-byte packet size): 178.5 Mpps
Capacity	ACL: 100 ¦ Virtual interfaces (VLANs): 256 ¦ ARP entries: 738 ¦ Priority queues: 8 ¦ IPv4 routes: 32 ¦ IPv6 routes: 32 ¦ IGMP multicast groups: 512 ¦ DHCP snooping entries: 8000
MAC Address Table Size	16K entries
Jumbo Frame Support	9KB
Routing Protocol	IGMPv2, IGMP, IGMPv3, static IPv4 routing, static IPv6 routing, MLDv2, MLD
Remote Management Protocol	SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP
Encryption Algorithm	SSL, TLS
Authentication Method	RADIUS, TACACS+, Extensible Authentication Protocol (EAP)
Features	Flow control, auto-negotiation, IGMP snooping, Syslog support, DoS attack prevention, port mirroring, DiffServ support, store and forward, Broadcast Storm Control, full duplex mode, Multicast Storm Control, Unicast Storm Control, firmware upgradable, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, DHCP snooping, Access Control List (ACL) support, Quality of Service (QoS), MLD snooping, Dynamic ARP Inspection (DAI), LLDP support, Link Aggregation Control Protocol (LACP), Energy Efficient Ethernet, Multicast VLAN Registration (MVR), Dynamic VLAN Support (GVRP), dual firmware images, 2MB packet buffer, static routing, Multicast filtering function, Strict Priority (SP), 802.1x authentication, VoIP support, DiffServ Code Point (DSCP) support, 2 fans, Protocol-based VLANs support, NAS support, cable test, ICMP Router Discovery Protocol (IRDP), LLDP-MED, Private VLAN, protected ports, Weighted Round Robin (WRR), Auto VoIP
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3an, IEEE 802.3az
Processor	X ARM Cortex-A9: 600 MHz
RAM	512 GB
Flash Memory	264 MB
Status Indicators	Power, fan, link/activity/speed
Interfaces	12 x 10GBase-T - RJ-45 ¦ 2 x 10GBase-X - SFP+ ¦ 1 x USB - Type A - management
Power Device	Internal power supply
Power Consumption Operational	75.3 Watt
Included Accessories	Foot pad set
Rack Mounting Kit	Included
MTBF	938,178 hours
Compliant Standards	CISPR 22 Class A, cUL, EN 60950, UL 1950, CSA 22.2 No. 950, CB, CCC, FCC Part 15 A, C-Tick Class A, VCCI Class A, EN 55024, IEC 60950-1:2005 + A1:2009 + A2:2013, EN 55022 Class A, FCC CFR47 Part 15 B Class A, EN 60950-1:2006+A11:2009+A1:2010+A12:2011+A2:2013, IEC 950, ANSI C63.4-2014, ICES-003:2016 issue 6 Class A, AS/NZS CISPR22:2009+A1:2010 Class A, IEC60950-1:2005, Second edition + A1:2009 + A2:2013, AN/NZS 60950.1:2015
Localisation	Latin America, North America, Europe
Software Included	Drivers & Utilities
Width	44 cm
Depth	20.4 cm
Height	4.3 cm
Weight	2.87 kg
Service & Support	NETGEAR lifetime warranty
Min Operating Temperature	0 °C
Max Operating Temperature	50 °C
Humidity Range Operating	90% (non-condensing)
Min Storage Temperature	-10 °C
Max Storage Temperature	70 °C
Humidity Range Storage	95% (non-condensing)
