Special Features
- ST type multi-mode fiber port connects over distances of up to 2km
- 10/100Base-TX port supports Auto-Negotiation, Auto-MDIX and Full-Duplex mode
- Functions as a stand alone converter or with the TFC-1600 fiber chassis
- Compliant with IEEE 802.3 10Base-T and IEEE 802.3u 100Base-TX / 100Base-FX standards
- One 10/100Base-TX auto-negotiation RJ-45 port
- Auto-negotiation 10/100Mbps connection speed and Half/Full-duplex mode on TX port
- Auto MDIX for 10/100Base-TX port
- One 100Mbps fiber port with Multi-mode ST-Type Connector
- Half / Full-Duplex mode selector on Fiber port
- Status LED indicators for Power, Link/Activity, Full-Duplex, and Speed
- Wall-Mountable
- Optional 19" system chassis with redundant power supply (TFC-1600), holds up to 16 TFC series Media Converters
Product Specification
| Device Type | Fibre media converter |
| Form Factor | External |
| Networking | Networking |
| Connectivity Technology | Wired |
| Cabling Type | 10Base-T, 100Base-FX, 100Base-TX |
| Data Link Protocol | 10Mb LAN, 100Mb LAN |
| Data Transfer Rate | 100 Mbps |
| Max Transfer Distance | 2 km |
| Status Indicators | Port transmission speed, port duplex mode, power, link/activity |
| Features | Full duplex capability, auto-sensing per device, MDI/MDI-X switch, auto-negotiation |
| Compliant Standards | IEEE 802.3, IEEE 802.3u |
| Expansion / Connectivity | Expansion / Connectivity |
| Interfaces | 1 x Ethernet 100Base-FX - ST multi-mode female x 2 ¦ 1 x Ethernet 10Base-T/100Base-TX - RJ-45 female |
| Miscellaneous | Miscellaneous |
| Rack Mounting Kit | Optional |
| Compliant Standards | VCCI |
| Power | Power |
| Power Device | External power adapter |
| Power Provided | 7.2 Watt |
| Dimensions & Weight | Dimensions & Weight |
| Width | 12 cm |
| Depth | 8.8 cm |
| Height | 2.5 cm |
| Weight | 0.4 kg |
| Manufacturer Warranty | Manufacturer Warranty |
| Service & Support | Limited warranty - lifetime |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 40 °C |
| Humidity Range Operating | 10 - 90% |
Χαρακτηριστικά
Product Code
04:190317
EAN Code
0710931504101
Manufacturer
Trendnet
