Chieftec Elox Series AS-01B-OP - Tower - ATX (ATX) - black - USB/Audio | AS-01B-OP
Please sign in so that we can notify you about a reply
Special Fetures
- Elegant and modern design
- Optimal cooling compatibility
- Support 280 mm radiator
- 1x 120 mm PWM fan pre-installed
Product Specification
| Form Factor | Tower |
| Max Mainboard Size | ATX |
| Supported Motherboards | ATX, microATX, Mini-ITX |
| Internal Bays Qty | 4 |
| Product Material | 0.5 mm SPCC steel |
| Colour | Black |
| Cooling System | Front: fan mount x 3 / 3 x 120 mm or 2 x 140 mm fan supported or 1 x 360/280mm radiator supported ¦ Rear: 120 mm fan mount x 1 ¦ Top: fan mount x 2 / 2 x 120 mm fan or 2 x 140 mm fan supported |
| CPU Cooler Max Height | 170 mm |
| Video Card Max Length | 320 mm |
| Expansion / Connectivity | |
| Expansion Bays | 2 (total) / 2 (free) x internal - 3.5" ¦ 2 (total) / 2 (free) x internal - 2.5" |
| Expansion Slots | 7 |
| Interfaces | 2 x USB 3.1 Gen 1 ¦ 1 x USB 2.0 ¦ 1 x headphones - mini-jack ¦ 1 x microphone - mini-jack |
| Power | |
| Power Device | Power supply |
| Specification Compliance | ATX |
| Dimensions & Weight | |
| Width | 21.2 cm |
| Depth | 40.5 cm |
| Height | 46.2 cm |
| Weight | 4.29 kg |
| Dimensions & Weight (Shipping) | |
| Shipping Weight | 5.1 kg |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 2 years |
Features - Chieftec - AS-01B-OP
More Details
Product Code
07:135253
EAN Code
0753263078032
Manufacturer
Chieftec
