CORSAIR iCUE LINK FRAME 4500X LX-R RGB Mid tower extended ATX windowed side panel (tempered glass) / no power supply (ATX) / white / USB/Audio | CC-9011317-WW
Brand: Corsair
CORSAIR iCUE LINK FRAME 4500X LX-R RGB Mid tower extended ATX windowed side panel (tempered glass) / no power supply (ATX) / white / USB/Audio | CC-9011317-WW
€389.01 inc. VAT
CC-9011317-WW
Delivery
Order Today...
Ships...
Delivery...
ℹ️ Large or fragile items (e.g. monitors) may require extra handling time. We'll keep you informed.
Payment options
Trusted Tech Choice
Buying Benefits
Verified
Competitive EU pricing
Delivered to Cyprus from EU stock
Local warranty support
Please sign in so that we can notify you about a reply
Product Features
- Spacious design
The chassis supports graphics cards up to 460 mm and CPU coolers up to 185 mm, accommodating a variety of high-performance components. - Optimized airflow
Features like the 3D Y-pattern airflow front panel and multiple vented areas ensure excellent cooling and airflow throughout the system. - Versatile RGB compatibility
Equipped with ARGB fans and compatible with major RGB synchronization technologies for a customized lighting experience. - Efficient cable management
A cable management system with 34 mm clearance helps maintain a clean and organized build, enhancing overall aesthetics. - Showcase-ready
The one-piece panoramic tempered-glass side panel allows users to display their build while protecting components from dust.
Special Fetures
- Mid-tower form factor with ample internal space for high-performance components
- Enhanced airflow through 3D Y-pattern front panel and multiple ventilation options
- ARGB fan support with compatibility for various RGB sync technologies
- Robust cable management system for a tidy build
- Tempered-glass side panel for showcasing internal components
Product Specification
| Form Factor | Mid tower |
| Windowed Side Panel | Yes |
| Windowed Side Panel Material | Tempered glass |
| Max Mainboard Size | Extended ATX |
| Supported Motherboards | Extended ATX, ATX, microATX, Mini-ITX |
| Internal Bays Qty | 3 |
| Product Material | Steel, tempered glass, plastic |
| Colour | White |
| Cooling System | Side: 120 mm fan x 3 / intake / ARGB PWM fan, supports 2 x 140 mm fans or 240/280/360 mm radiator, reverse rotor <br /> Top: 120 mm fan mount x 3 / 2 x 140 mm fan or 240/280/360mm radiator supported <br /> PSU shroud: 120 mm fan mount x 2 <br /> Bottom: 120 mm fan mount x 1 <br /> Rear: 120 mm fan mount x 1 / 1 x 140 mm fan or 120/140 mm radiator supported |
| CPU Cooler Max Height | 185 mm |
| Video Card Max Length | 460 mm |
| Power Supply Max Length | 250 mm |
| System Cabinet Features | InfiniRail fan mounting system, 1-piece panoramic glass, ARGB fans, support back-connect motherboard, 3D Y-parttern airflow front panel, cable management system (34 mm clearance), side panel dust filter, PSU dust filter, compatible with ASUS Aura Sync RGB illumination, compatible with ASRock Polychrome SYNC, compatible with MSI RGB Mystic Light Sync, Gigabyte RGB Fusion 2.0 Ready, ventilated top panel, ventilated side panel |
| Expansion / Connectivity | |
| Expansion Bays | 1 (total) / 1 (free) x internal - 3.5" <br /> 2 (total) / 2 (free) x internal - 2.5" |
| Expansion Slots | 7 x horizontal <br /> 3 x vertical |
| Interfaces | 2 x USB 3.2 Gen 1 <br /> 1 x USB-C 3.2 Gen 2 <br /> 1 x headphone/microphone - mini-jack |
| Miscellaneous | |
| Included Accessories | Graphic card holder, accessory box, 3 iCUE LINK LX120-R RGB fans, cable ties, iCUE LINK System Hub, iCUE LINK cable 90° |
| Power | |
| Power Device | No power supply |
| Specification Compliance | ATX |
| Max Supported Qty | 1 |
| Dimensions & Weight | |
| Width | 24.6 cm |
| Depth | 49.9 cm |
| Height | 47.8 cm |
| Weight | 11.58 kg |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 2 years |
Features - Corsair - CC-9011317-WW
More Details
Product Code
04:546291
EAN Code
0840440402800
Manufacturer
Corsair
