Grandstream GWN7603 Wi-Fi 5 Access Point | Dual-Band | PoE+
The Grandstream GWN7603 is an indoor wall-mountable radio access point for wireless networking in business or home environments. It supports dual-band Wi-Fi 5, PoE+ power and up to 100 concurrent clients, with a compact design and included wall mounting kit.
Technical Specifications
| Specification | Detail |
|---|---|
| Product Type | Radio access point |
| Wireless Standard | IEEE 802.11b / IEEE 802.11a / IEEE 802.11g / IEEE 802.11n / IEEE 802.11ac Wave 2 | IEEE 802.11b / 802.11a / 802.11g / 802.11n / 802.11ac Wave 2 |
| Wi-Fi Band | 2.4 GHz | 5 GHz | 2.4 GHz, 5 GHz |
| Data Transfer Rate | 1.27 Gbps |
| Maximum Data Rate (2.4 GHz) | 400 Mbps |
| Maximum Data Rate (5 GHz) | 867 Mbps |
| Channel Bandwidth (2.4 GHz) | 20 / 40 MHz |
| Channel Bandwidth (5 GHz) | 20 / 40 / 80 MHz |
| Capacity | Up to 100 concurrent clients | 8 SSIDs per radio | 16 SSIDs total |
| Interfaces | 1 x 1000Base-T (uplink, PoE+ input) - RJ-45 | 1 x 10/100/1000Base-T - RJ-45 | 2 x 10/100/1000Base-T (PoE) - RJ-45 |
| Antenna | 2 | Internal |
| Power | PoE+ |
| Security | WEP | WPA2-PSK | WPA-PSK | WPA2-Enterprise | WPA-Enterprise | TKIP | AES | WPA3 |
| Features | 2x2:2 MU-MIMO technology | secure boot | Advanced QoS | reset button | security slot (Kensington security lock compatible) | LED status indicator | Wi-Fi Multimedia (WMM) support | VLAN support | Type of Service (ToS) | 12W PoE power budget |
| Form Factor | Wall mountable - indoor |
| Dimensions | 13.5 cm x 11.5 cm x 3 cm |
| Weight | 215 g |
| Package Contents | Wall mounting kit |
| Compliant Standards | FCC | IC | RCM |
| Network / Transport Protocol | IPv6 | IPv4 |
| Line Coding Format | 256 QAM |
| Max Range Open Space | 100 m |
| Operating Temperature | 0 °C to 45 °C |
| Operating Humidity | 10 - 90% (non-condensing) |
| SKU / EAN | GWN7603 | 6947273704997 |
SINGULAR RECOMMENDS
For who
Suitable for shoppers who need a compact indoor access point with dual-band Wi-Fi 5, PoE+ power and support for multiple connected devices.
Real reason to buy it
A practical choice if you want a wall-mountable access point with Wi-Fi 5, PoE+ installation and WPA3 security in one compact unit.
Know before
This is an indoor wall-mountable access point only. The listing includes a wall mounting kit, and the supported performance and client capacity are as specified by the product data.
Features - Grandstream - GWN7603
More Details
Product Code
04:482119
EAN Code
6947273704997
Manufacturer
Grandstream
