PLANET GS-6311-24T4X 24-Port Gigabit Layer 3 Managed Switch 4x 10G SFP+ OSPF RIP Fanless 1U Rackmount

Brand:
Planet
PLANET Layer 3 24-Port 10/100/1000T, Managed, L3, | GS-6311-24T4X
PLANET GS-6311-24T4X 24-Port Gigabit Layer 3 Managed Switch 4x 10G SFP+ OSPF RIP Fanless 1U Rackmount
€385.5 inc. VAT
Buy
GS-6311-24T4X
€323.95 €359.95
€385.50 inc. VAT
Ships from EU stock: 3 item(s)
+ −
Add to wish list Ask a question
Product Code
04:511324
EAN Code
4711605287258
Manufacturer
Planet

Quick Specs

Ports
24× GbE + 4× 10G SFP+
Management
Layer 3 (OSPF/RIP)
Capacity
128 Gbps non-blocking
Cooling
Fanless
Delivery

Order Today...
Ships...
Delivery...
ℹ️ Large or fragile items (e.g. monitors) may require extra handling time. We'll keep you informed.
Payment options
✓ Bank Deposit
Secure checkout with flexible payment methods
Trusted Tech Choice
Buying Benefits Verified
Competitive EU pricing
Delivered to Cyprus from EU stock
Local warranty support

PLANET GS-6311-24T4X 24-Port Gigabit Layer 3 Managed Switch

24× Gigabit4× 10G SFP+Layer 3 OSPF/RIPFanless 128Gbps

The PLANET GS-6311-24T4X is a 24-port Gigabit Layer 3 managed switch with four 10G SFP+ uplinks, built as a fanless aggregation and backbone switch for enterprise and campus networks. Part number GS-6311-24T4X delivers full Layer 3 routing — static, RIP and OSPF — with a 128 Gbps non-blocking fabric and 1,024 IP interfaces, in a rugged, silent 1U chassis. Typically in stock with fast delivery across Cyprus.

Compatibility — check before buying:
This is a full Layer 3 switch with OSPF and RIP dynamic routing, not just VLAN routing. It has no PoE, so cameras or access points needing power require a separate PoE switch or injector. The four 10G SFP+ ports are fibre or DAC (backward compatible with 1G SFP); modules are purchased separately. The 24 access ports are Gigabit copper.

Best For

✓Enterprise and campus backbone / aggregation
✓Inter-VLAN and dynamic routing (OSPF/RIP)
✓10G fibre core links between switches
✓Silent, fanless server rooms and closets
✓Multi-subnet and multi-tenant networks
✓Core switch upstream of edge PoE switches

Key Features


Full Layer 3 Routing
Static routing plus RIP v1/v2 and OSPFv2 dynamic routing, with 1,024 IP interfaces, make this a true routing core — not just an L2+ switch with VLAN routing.

24× Gigabit + 4× 10G SFP+
Twenty-four Gigabit copper access ports and four 10G SFP+ uplinks give you dense connectivity with a high-speed fibre backbone.

128 Gbps Non-Blocking Fabric
A 128 Gbps non-blocking switch fabric with 95 Mpps throughput and a 12MB buffer handles demanding backbone and data-centre traffic.

Fanless, Rugged Design
A silent, fanless 1U rugged chassis suits quiet offices and reliable server-room operation with no moving parts to fail.

Technical Specifications

Identification
Brand PLANET
Model GS-6311-24T4X
EAN / GTIN 4711605287258
MPN GS-6311-24T4X
Ports
Access Ports 24× 10/100/1000 RJ45
10G Uplinks 4× 10GBASE-SR/LR SFP+ (1G compatible)
PoE None
Switching & Routing
Switch Type Layer 3 Managed
Switching Capacity 128 Gbps non-blocking
Throughput 95.23 Mpps
Routing Static, RIP v1/v2, OSPFv2
IP Interfaces 1,024
Multicast IGMP v1/v2/v3
Physical
Dimensions 440 × 207 × 44 mm (1U)
Weight 2.74 kg
Cooling Fanless
Mounting Rackmount
Power Internal PSU
Warranty
Warranty PLANET limited manufacturer warranty. Singular's direct warranty is 1 year; beyond that we assist you with the manufacturer's warranty process.

Frequently Asked Questions

Does the GS-6311-24T4X supply PoE?
No. The T4X model is a non-PoE Layer 3 switch. If you need to power cameras or access points, use a separate PoE switch or midspan injector, or choose a PoE variant in the GS-6311 series.
Is it a full Layer 3 switch?
Yes. It supports static routing plus RIP v1/v2 and OSPFv2 dynamic routing with 1,024 IP interfaces, making it suitable as a routing core, not just for inter-VLAN routing.
Are the 10G ports copper or fibre?
They are 10G SFP+ slots for fibre transceivers or DAC cables (also backward compatible with 1G SFP). They are not 10GBASE-T copper. Modules are added separately.
Is the switch silent?
Yes. It uses a fanless design, so it runs silently with no moving parts — ideal for quiet offices and reliable server-room deployment.
Singular Expert Insight
The GS-6311-24T4X is a genuine routing core: OSPF and RIP support and a 128 Gbps fabric put it a class above L3-Lite switches, and the fanless design suits quiet, always-on operation. Remember it has no PoE — pair it with an edge PoE switch for cameras and access points. To feed 10G to servers, add adapters from our network cards category. Browse more options in our network switches range.

Buyer's Guide

Buy it if
You need a true Layer 3 routing core with OSPF/RIP, 10G fibre uplinks and silent fanless operation for an enterprise or campus network.
Skip it if
You need PoE for cameras or access points, or you only need basic L2 VLAN switching (a smart switch is cheaper).
Also consider
A PoE variant such as the GS-6311-24P4X if you need power, or a smart L2+ switch for simpler networks.
